  9. Miniature Circuit Breaker, E FRAME Series, 15A, 1 Pole, 600V AC, 65kA at 120V AC
Square D Miniature Circuit Breaker, E FRAME Series, 15A, 1 Pole, 600V AC, 65kA at 120V AC EGB16015 - main

Miniature Circuit Breaker, E FRAME Series, 15A, 1 Pole, 600V AC, 65kA at 120V AC

  • Mfr # EGB16015

  • Zoro # G0846100

product price: $252.99
/ea
Free Shipping & Returns

Key Features

Series
E FRAME
Number of Poles
1
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
EGB16015
Zoro #
G0846100
UPC #
785901235729
Country of Origin
Mexico

Dimensions

Frame Size
125A/EGB
Width
0.98 in
Depth
4.05 in
Height
5.66 in
Max. Wire Size
6 AWG (Cu/Al)
Min. Wire Size
12 AWG (Al), 14 AWG (Cu)

Details

Item
Miniature Circuit Breaker
Series
E FRAME
Amps
15A
Number of Poles
1
AC Voltage Rating
600V AC
Circuit Breaker Type
Standard
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Bolt On
Max. AIR Rating
65kA at 120V AC
Trip Type
Thermal Magnetic
Terminal Connection
Lugs
DC Voltage Rating
Not Rated
Standards
cULus
Interrupt Rating
18 kA at 600Y/347V AC
High Amp Trip Setting
875 A
Features
Mercury Free
For Use With
NF Panelboard
Application
HACR rated Applications
Protection Type
Overload; Short-circuit
Ambient Air Temperature For Operation
104°F (40°C)
Module Type
E-Frame
Breaking Capacity
18 kA 600Y/347 V AC
AWG Gauge
AWG 12 to AWG 6 aluminium; AWG 14 to AWG 6 copper
Local Signalling
Trip indicator
Circuit Breaker Application
HACR rated
Breaking Capacity Code
G
Tightening Torque
30.09 lbf.in (3.4 N.m) 0.00 to 0.02 in² (2.5 to 16 mm²) (AWG 14 to AWG 6)
Holding Current
270 A

Description

Miniature Circuit Breaker 600V 15A, Series EGB
