Miniature Circuit Breaker, HOMELINE Series, 15A, 1 Pole, 120V AC, 10kA at 120V AC
Mfr # HOMT1515
Zoro # G2544866
CAD Available
product price:Â
$
18.39
/ea
Key Features
CAD Drawing
Series
HOMELINE
Number of Poles
1
AC Voltage Rating
120V AC
Circuit Breaker Type
Tandem
Phase
1
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- HOMT1515
- Zoro #
- G2544866
- UPC #
- 785901065388
- Country of Origin
- Mexico
Dimensions
- Frame Size
- 100A/HOM
- Width
- 1 in
- Depth
- 2.98 in
- Height
- 3.13 in
- Max. Wire Size
- 8 AWG
- Min. Wire Size
- 14 AWG
- Wire Size
- 1 x AWG 14 to AWG 8 ( aluminium/copper )
- Length
- 3.1 in
Description
Miniature Circuit Breaker, Amps 15 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type Tandem, Number of Poles 1, DC Voltage Rating Not Rated, Circuit Breaker Actuator Paddle, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series HOM, Phase Single, Series HOM, Max. AIR Rating 10kA at 120/240V AC, For Use With Homeline Load Center, Terminal Connection Lug, Frame Size 100A/HOM, Length 3.1 in, Width 1 in, Depth 3 in, Min. Operating Temp. 77 Degrees F
