Shop SQUARE D

Molded Case Circuit Breaker, 600V AC

  • Mfr # LAL36150MB

  • Zoro # G122587950

product price:
$
5,325.99
/ea
Free Shipping & Returns

Key Features

Amps
150A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Low Voltage
Circuit Breaker Actuator
Short Handle
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LAL36150MB
Zoro #
G122587950
UPC #
-
Country of Origin
Mexico

Dimensions

Frame Size
150A/LA
Width
6 in
Depth
5.84 in
Height
11 in
Min. Wire Size
1 AWG

Details

Item
Molded Case Circuit Breaker
Amps
150A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Low Voltage
Circuit Breaker Actuator
Short Handle
Circuit Breaker Mounting Style
Unit Mount
Max. AIR Rating
22kA at 600V AC
Trip Type
Thermal Magnetic
Instantaneous Trip
Fixed
Terminal Connection
Line/Load Lug
Phase Connection
Non-Applicable
DC Voltage Rating
250V DC
Application
HACR rated
Standards
CSA Certified, IEC Certified, REACH Regulation, RoHS Directive, UL Listed
Max. Operating Temp.
104 Degrees F
Low Amp Trip Setting
10 kA
High Amp Trip Setting
22 kA
Min. Operating Temp.
14 Degrees F
For Use With
Control Equipment Panels

Description

Molded Case Circuit Breaker, 150 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 22kA at 600V AC, For Use With Control Equipment Panels, High Amp Trip Setting 22 kA, Low Amp Trip Setting 10 kA, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Line/Load Lug, Trip Type Thermal Magnetic, Phase Not Applicable, Instantaneous Trip Fixed, Phase Connection Non-Applicable, Frame Size AL400LA, Circuit Breaker Mounting Style Unit Mount, Height 11 in
