Shop SQUARE D

Molded Case Circuit Breaker, LEGACY MCCB Series, 225A, 3 Pole, 600V AC, 42kA at 240VAC

  • Mfr # LAL362251021

  • Zoro # G0845166

product price:  $3,385.99
/ea
Free Shipping & Returns

Key Features

Series
LEGACY MCCB
Amps
225 A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Shunt Trip
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LAL362251021
Zoro #
G0845166
UPC #
785901119029
Country of Origin
Mexico

Dimensions

Frame Size
400A/LA
Width
6 in
Depth
5.84 in
Height
11 in

Details

Item
Molded Case Circuit Breaker
Series
LEGACY MCCB
Amps
225 A
Number of Poles
3
AC Voltage Rating
600V AC
Circuit Breaker Type
Shunt Trip
Phase
3
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Unit Mount
Max. AIR Rating
42kA at 240VAC
Trip Type
Thermal Magnetic
Terminal Connection
Lugs
Phase Connection
ABC
DC Voltage Rating
250V DC
High Amp Trip Setting
2250 A
Standards
UL Listed, IEC, CSA
Features
Mercury Free; PVC Free
Application
HACR rated Applications
Circuit Breaker Application
HACR rated
Terminal Identifier
AL400LA
Magnetic Hold Current
1125 A
Tightening Torque
115.06 lbf.in (13 N.m) 0.07 to 0.47 in² (42 to 304 mm²) (AWG 1 to 600 kcmil); 115.06 lbf.in (13 N.m) 0.07 to 0.20 in² (42 to 127 mm²) (AWG 1 to 250 kcmil)
Certifications
UL Listed; IEC; CSA

Description

Molded Case Circuit Breaker 600V 225A

Documents & Resources
