Power Distribution Block, 3 Pole, 30 A, 600 V, 10 AWG
- Mfr # 9080FB3611CC
- Zoro # G0852945
product price:Â
$
26.95
/ea
Key Features
Connection Type
Screw Clamp
Number of Poles
3
Current
30 A
Maximum Voltage
600 V
For Minimum Wire Size
14 AWG
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 9080FB3611CC
- Zoro #
- G0852945
- UPC #
- 785901097211
- Country of Origin
- Korea, Republic of
Dimensions
- For Minimum Wire Size
- 14 AWG
- For Maximum Wire Size
- 10 AWG
- Overall Length
- 3.13 in
- Overall Width
- 2.35 in
- Wire Stripping Length
- 0.4375 in
- Fuse Size
- 0.4063 x 1.5 in
- Overall Depth
- 1.29 in
Details
- Item
- Power Distribution Block
- Connection Type
- Screw Clamp
- Number of Poles
- 3
- Current
- 30 A
- Maximum Voltage
- 600 V
- Standards
- CE || UL recognized E40747 CCN IZLT2 || CSA file 70360 class 6225 01
- Material
- thermoplastic block
- Block Material
- Thermoplastic: block
- Ambient Air Temperature For Operation
- -40-257°F
- Electrical Connection
- pressure wire clamp
- Fuse Type
- CC
- [Ics] Rated Service Breaking Capacity
- 200 kA UL 512
- [Ue] Rated Operational Voltage
- <= 600 V AC/DC
- Terminal Tightening Torque
- screw terminals 25 lbf.in (2.82 N.m) AWG 14 to AWG 10 copper
- Operating Temperature
- -40 to 257°F (-40 to 125°C)
Description
Terminal Block Fuseholder 600V 30A
