  6. Relay, 600VAC Coil Volts, 1 NO; SPST

This item is Discontinued.

Square D Relay, 600VAC Coil Volts, 1 NO; SPST 8501CDO6V53

Relay, 600VAC Coil Volts, 1 NO; SPST (Discontinued)

  • Mfr # 8501CDO6V53
  • Zoro # G0847248
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8501CDO6V53
Zoro #
G0847248
UPC #
785901052050
Country of Origin
China

Dimensions

Body Height - Relay
2.43 in
Body Width - Relay
2-1/2 in
Body Depth - Relay
2-1/4 in
Width
2.5 in
Depth
2.25 in

Details

Item
Relay
Coil Volts
600VAC
Contact Form - Relay
1 NO; SPST
Mounting - Relay
Panel Mount
Power Consumption - Relay
2 W
Standards
UL listed file E78351 CCN NLDX; CSA; CE
Switching Voltage
600 V AC
Series
type C
Current Rating
30 A
Operating Temp. Range
-22-140°F
Status Indicator
No Indicator
Hold-In Power Consumption In W
2-2 W
Contacts Type And Composition
1 NO
Tightening Torque
11-15 lbf.in
Awg Gauge
AWG 10 copper
Connections - Terminals
screw clamp terminal
Phase
1 phase
Range of Product
Power Relay 8501C
[Uc] Control Circuit Voltage
24 V DC
Ambient Air Temperature For Operation
-22-140°F
Mounting Support
panel mounting
Rated Power In Hp
2 hp
Switch Function
SPST
Device Application
suited for controlling small single phase motors and other light loads
Product or Component Type
power relay

Description

Relay, Status Indicator No Indicator
