  11. Diamond Turning Insert, Diamond, 4, CNMA, 2, Carbide
Sumitomo Diamond Turning Insert, Diamond, 4, CNMA, 2, Carbide CNMA432-AC700G - main

Diamond Turning Insert, Diamond, 4, CNMA, 2, Carbide

  • Mfr # CNMA432-AC700G

  • Zoro # G3764607

product price: $9.79
/ea
Sold in multiples of 10 for $97.90

Key Features

Insert Shape
Diamond
Insert Style
CNMA
Inscribed Circle
4
Insert Size
432
Chip-Breaker
No
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CNMA432-AC700G
Zoro #
G3764607
UPC #
-
Country of Origin
Japan

Dimensions

Insert Size
432
Corner Radius
2
Nose Radius
0.0312"
Mounting Hole Dia.
0.203
Insert Thickness
0.1875"
Thickness
3

Details

Item
Diamond Turning Insert
Insert Shape
Diamond
Insert Style
CNMA
Inscribed Circle
4
Chip-Breaker
No
Grade
AC700G
Insert Material
Carbide
Insert Application
Roughing
Rake
0 Degrees
ISO Number
CNMA120408
Relief Angle
0 Degrees
Super Alloy (S) Compatibility
No
Cutting Direction
Neutral
Hardened (H) Compatibility
No
For Use With
DCLN, MCLN, Toolholders, A-MCLN Boring Bars
Steel (P) Compatibility
No
Coating
Super FF TiCN/Al2O3/TiN CVD
Workpiece Compatibility
Cast Iron (K)
No. of Edges
4
Mounting Style
Clamp
ANSI Number
CNMA432-AC700G
Non Ferrous (N) Compatibility
No
Stainless (M) Compatibility
No
Cast Iron (K) Compatibility
Yes
Features
Excellent Wear Resistance
Insert Holding Type
Straight Hole
ANSI Code
CNMA432
Manufacturer Grade
AC700G
Coating Process
CVD
Cutting Application
Turning
Measurement System
Fractional Inch
Primary Material Application ISO Code
P
Material - Machining
Carbide
Shape
Rhombic
Included Angle
80 Degrees
Clearance Angle
0 Degrees
Number of Cutting Edges
4
Finish - Machining
Al203+TiCN
Primary Material Application
Steel
Material
Carbide
Style
CNMA

Description

Diamond Turning Insert, Inscribed Circle 1/2 in, Al203+TiCN, ANSI Code CNMA432, Clearance Angle 0 Degrees , Coating Process CVD
