Sumitomo Diamond Turning Insert, Diamond, 5, CNMM, 2, Carbide CNMM542ENP-AC5015S - main

Diamond Turning Insert, Diamond, 5, CNMM, 2, Carbide

  • Mfr # CNMM542ENP-AC5015S

  • Zoro # G7551277

product price: $16.79
/ea
Sold in multiples of 10 for $167.90

Key Features

Insert Shape
Diamond
Insert Style
CNMM
Inscribed Circle
5
Insert Size
542
Chip-Breaker
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CNMM542ENP-AC5015S
Zoro #
G7551277
UPC #
-
Country of Origin
Japan

Dimensions

Insert Size
542
Corner Radius
2
Insert Thickness
0.250"
Mounting Hole Dia.
0.250"
Nose Radius
0.031"
Thickness
4

Details

Item
Diamond Turning Insert
Insert Shape
Diamond
Insert Style
CNMM
Inscribed Circle
5
Chip-Breaker
Yes
Grade
AC5015S
Insert Material
Carbide
Insert Application
Roughing
Rake
Negative
ISO Number
CNMM160608N-MP
For Use With
Toolholders, Boring Bars
Relief Angle
0 Degrees
Hardened (H) Compatibility
No
Cast Iron (K) Compatibility
Yes
Steel (P) Compatibility
Yes
Non Ferrous (N) Compatibility
Yes
ANSI Number
CNMM542ENP
No. of Edges
4
Super Alloy (S) Compatibility
Yes
Mounting Style
Screw
Cutting Direction
Neutral
Workpiece Compatibility
Cast Iron (K), Nonferrous (N), Stainless (M), Steel (P), Super Alloy (S)
Coating
PVD
Stainless (M) Compatibility
Yes
ANSI Code
CNMM542ENP
Cutting Application
Turning
Manufacturer Grade
AC5015S
Insert Holding Type
Straight Hole
Features
Excellent Wear Resistance
Measurement System
Fractional Inch
Shape
Rhombic
Primary Material Application
Aluminum, Brass, Bronze, Cast Iron, Copper, Magnesium, Nickel, Stainless Steel, Steel, Titanium
Material - Machining
Carbide
Chip-Breaker Code
ENP
Included Angle
80 Degrees
Number of Cutting Edges
4
Finish - Machining
AlTiSiN
Clearance Angle
0 Degrees
Chip-Breaker Style
Single
Primary Material Application ISO Code
K, M, N, P, S
Material
Carbide

Description

Diamond Turning Insert, Chip-Breaker Code ENP, Inscribed Circle 5/8 in, AlTiSiN, ANSI Code CNMM542ENP, Chip-Breaker Style Single, Clearance Angle 0 Degrees
