Sumitomo Turning Insert, Diamond, 0.375 in., VNMG, 2, Carbide VNMG332EEG-AC6030M - main

Turning Insert, Diamond, 0.375 in., VNMG, 2, Carbide

  • Mfr # VNMG332EEG-AC6030M

  • Zoro # G6379530

product price: $17.15
/ea
Sold in multiples of 10 for $171.50

Key Features

Insert Shape
Diamond
Insert Style
VNMG
Inscribed Circle
0.375 in.
Insert Size
332
Chip-Breaker
EEG
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
VNMG332EEG-AC6030M
Zoro #
G6379530
UPC #
-
Country of Origin
Japan

Dimensions

Insert Size
332
Corner Radius
2
Mounting Hole Dia.
0.150"
Nose Radius
0.0313"
Insert Thickness
0.1875"
Thickness
3

Details

Item
Turning Insert
Insert Shape
Diamond
Insert Style
VNMG
Inscribed Circle
0.375 in.
Chip-Breaker
EEG
Grade
M30, M35, M30
Insert Material
Carbide
Insert Application
Medium
Rake
Positive
ISO Number
VNMG160408N-EG
Hardened (H) Compatibility
No
Cutting Direction
Neutral
Cast Iron (K) Compatibility
No
ANSI Number
VNMG332EEG-AC6030M
Non Ferrous (N) Compatibility
No
No. of Edges
2
Workpiece Compatibility
Stainless (M)
Steel (P) Compatibility
No
For Use With
Toolholders, Boring Bars
Mounting Style
Top and Hole Clamping
Super Alloy (S) Compatibility
No
Coating
CVD
Stainless (M) Compatibility
Yes
Relief Angle
0
Finish - Machining
Absotech
Primary Material Application ISO Code
M
Manufacturer Grade
AC6030M
Shape
Rhombic
Primary Material Application
Stainless Steel
Features
Fracture Resistant
Insert Holding Type
Straight Hole
Measurement System
Fractional Inch
ANSI Code
VNMG332EEG
Cutting Application
Turning
Clearance Angle
0 Degrees
Number of Cutting Edges
2
Included Angle
35 Degrees
Coating Process
CVD
Chip-Breaker Style
Double
Material - Machining
Carbide
Chip-Breaker Code
EEG
Material
Carbide
Style
VNMG
Application
Medium
Series
AC6000M
Chip Breaker
EEG
Corner Angle
35

Description

Diamond Turning Insert, Chip-Breaker Code EEG, Inscribed Circle 3/8 in, Absotech, ANSI Code VNMG332EEG, Chip-Breaker Style Double, Clearance Angle 0 Degrees , Coating Process CVD
