Suretest AC Circuit Analyzer, 85 to 265V 61-164

AC Circuit Analyzer, 85 to 265V (Discontinued)

  • Mfr # 61-164
  • Zoro # G4101711
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
61-164
Zoro #
G4101711
UPC #
783250717484
Country of Origin
United States

Dimensions

Manufacturers Warranty Length
2 yr
Power Cord Length
12 in
Manufacturer Warranty Length
2 yr

Details

Item
AC Circuit Analyzer
Safety Rating
CAT III 300V
Standards
UL
Includes
1 ft Extension Cord, Carrying Case
Voltage
85 to 265V AC
Frequency Range
45 to 65 Hz
Load Current
12 A, 15 A, 20 A
Voltage Drop
0.1% to 50.0%
Ground Impedance
0.00 to 1.99 ohm
Indicator
Digital
NEMA Plug Configuration
5-15P
Features
Estimates Load on Line (ELL) up to 15A, Line and Peak Voltage, Measures Voltage Drop Under Load, Tests Without Disturbing Sensitive Loads, True RMS, Verifies Isolated Grounds (with 61-176 Adapter)
For Voltage Range
85 to 265V AC
Tester Type
GFCI Tester and AC Circuit Analyzer
Display Screen Type
OLED
Alert Type
Digital Display
Frequency Rating
45 to 65 Hz
Display Type
Digital
Testing Functions
Correct Wiring, Equipment Protection Devices, GFCI Testing, Reverse Polarity, Open Ground, Open Hot, Open Neutral
Wiring Alerts
Correct Wiring, Hot Terminal Unwired, Hot Wire on Neutral Terminal, Hot/Ground Reverse, Hot/Neutral Reverse (Reverse Polarity), Open Ground, Open Hot, Open Neutral
CAT Safety Rating
CAT III 300V
Voltage Rating - Minimum
85 V AC
Voltage Rating - Maximum
265 V AC
Ground Impedance - Maximum
1.99 ohm

Description

AC Circuit Analyzer, Alert Type Digital Display, CAT Safety Rating CAT III 300V, Display Screen Type OLED, Display Type Digital, Features Estimates Load on Line (ELL) up to 15A, Line and Peak Voltage, Measures Voltage Drop Under Load, Tests Without Disturbing Sensitive Loads, True RMS, Verifies Isolated Grounds (with 61-176 Adapter), For Voltage Range 85 to 265V AC, Frequency Rating 45 to 65 Hz, Ground Impedance 0.00 to 1.99 ohm, Includes 1 ft Extension Cord, Carrying Case
