Contact our U.S. based teamSpecifications
Product Information
MFR #
179975-1
Zoro #
G800984187
UPC #
-
Country of Origin
China
Dimensions
Wire Size
15 - 10 AWG
Overall Length
.834 in
Mating Tab Width
.25 in
Receptacle Stock Thickness
.016 in
Mating Tab Thickness
.032 in
Accepts Wire Insulation Diameter Range
.118 - .169 in
Wire Insulation Diameter (Max)
.169 in
Details
Terminal Type
Receptacle
Discrete Wire Type
Stranded
Crimp Type
F-Crimp
Wire Insulation Support
With
Barrel Type
Open
Terminal Orientation
Straight
Wire/Cable Type
Discrete Wire
Terminates To
Wire & Cable
Fully Insulated
No
Insertion Force
Low
UL Rating
Recognized
Plating Material
Pre-Tin
Operating Temperature Range
-40 221 °F
Contact Base Material
Brass
Terminal & Splice Style
Receptacle
Mating Retention Type
Dimple
