Shop TE CONNECTIVITY

CT P/HDR ASSY V 8P W/KINK BLUE

  • Mfr # 2-292161-8

  • Zoro # G600938502

product price:
$
0.61
/ea
Sold in multiples of 300 for $183.00

Key Features

Color
Blue
Min. Single Wire Size
28 AWG
Max. Voltage
125V AC/DC
Maximum Voltage
125 V AC/DC
Current
4 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
2-292161-8
Zoro #
G600938502
UPC #
-
Country of Origin
China

Dimensions

Min. Single Wire Size
28 AWG
Width
0.141 in
Height
0.267 in
Max. Single Wire Size
22 AWG
Length
17.8 mm
Contact Plating Thickness
1 to 2 µm
Maximum Single Wire Size
22 AWG
Minimum Single Wire Size
28 AWG

Details

Item
Connector
Color
Blue
Max. Voltage
125V AC/DC
Maximum Voltage
125 V AC/DC
Current
4 A
Standards
CSA Certified; UL E28476
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Connection Material
Brass
Hole Center to Center
2 mm
Max. Temp.
105°C
Material
Nylon
Terminal Type
Through Hole - Solder
Wire Type
Discrete
For Use With
Printed Circuit Board
Features
Partially Shrouded
Connector Type
Header
Number of Contacts
8
Current Rating
4 A
Number of Rows
1
Contact Finish
Tin Plated
Contact Type
Pin
Flammability Rating
UL 94 V-0
Terminal Finish
Tin Plated
