Contact our U.S. based teamSpecifications
Product Information
MFR #
150571-2
Zoro #
G500965943
UPC #
-
Country of Origin
Italy
Dimensions
Wire Size
24 - 20 AWG
Overall Length
.625 in
Mating Tab Width
.11 in
Mating Tab Thickness
.031 in
Receptacle Stock Thickness
.01 in
Accepts Wire Insulation Diameter Range
.059 - .079 in
Details
Terminal Type
Receptacle
Wire/Cable Type
Regular Wire
Operating Temperature Range
-40 266 °F
Insertion Force
Normal
Connection Capacity
Single
Disconnect Type
Quick Disconnect
Contact Base Material
Brass
Terminal Orientation
Straight
FASTON
Yes
Crimp Type
F-Crimp
Terminal & Splice Style
Receptacle
Barrel Type
Open
Mating Retention Type
Locking Lance
Plating Material
Tin
Fully Insulated
Yes
Terminates To
Wire & Cable
Insulated
Yes
Wire Insulation Support
With
