Shop TE CONNECTIVITY

Header Assembly Right Angle 12 Circuit

  • Mfr # 5794176-2
  • Zoro # G400979583
product price:
$
14.15
/ea
Sold in multiples of 10 for $141.50

Key Features

Color
White
Insulation Material
Glass-Filled PBT
Max. Voltage
600V AC
Maximum Voltage
600 V AC
Application
Power, Signal
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
5794176-2
Zoro #
G400979583
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
0.76 µm

Details

Item
Header
Color
White
Insulation Material
Glass-Filled PBT
Max. Voltage
600V AC
Maximum Voltage
600 V AC
Application
Power, Signal
Current
9 A
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Connection Material
Brass
Material
Glass-Filled PBT
Terminal Type
Through Hole - Solder
Hole Center to Center
4.2 mm
Max. Temp.
105°C
Number of Contacts
12
Contact Type
Pin
Number of Rows
2
Contact Finish
Gold Plated
Current Rating
9 A
Terminal Finish
Tin Plated
Connector Terminates To
Printed Circuit Board
Flammability Rating
UL 94 V-0
