MICRO MNL HDR ASSY S/ROW AU LF
Mfr # 2-1445088-2
Zoro # G200938544
product price: $0.94
/eaSold in multiples of 93 for $87.42
Key Features
Color
Black
Insulation Material
High Temperature Nylon
Max. Voltage
250V AC/DC
Maximum Voltage
250 V AC/DC
Application
Power
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
2-1445088-2
Zoro #
G200938544
UPC #
-
Country of Origin
China
Dimensions
Length
7.43 mm
Contact Plating Thickness
0.38 µm
Details
Item
Header
Color
Black
Insulation Material
High Temperature Nylon
Max. Voltage
250V AC/DC
Maximum Voltage
250 V AC/DC
Application
Power
Current
5 A
Standards
CSA Certified; UL E28476; UL Recognized
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Hole Center to Center
3 mm
Max. Temp.
105°C
Material
High Temperature Nylon
Terminal Type
Through Hole - Solder
Current Rating
5 A
Number of Rows
1
Contact Finish
Gold Plated
Contact Type
Pin
Number of Contacts
2
Terminal Finish
Tin Plated
Connector Terminates To
Printed Circuit Board
Flammability Rating
UL 94 V-0
