Contact our U.S. based teamSpecifications
Product Information
MFR #
9-1415534-2
Zoro #
G401026552
UPC #
-
Country of Origin
Austria
Details
Item
Power Relay
Mounting Style
DIN Rail
Electrical Connection
Screw Terminals
Coil Voltage
115V AC
Contact Form
2 Form C (CO)
Power Consumption - Relay
1VA
Features
Manual Operation; Electrical Indicator, LED
Number of Poles
2
Item - Relay
Relay Package PT
Contact Material
AgNi90/10
Dielectric Voltage
2500 Vrms Adjacent Contacts; 1200 Vrms Coil and Contact; 2500 Vrms Open Contacts
Coil Type
Monostable, AC
Coil Resistance
4845 Ω
Contact Limiting Making Current
24A
Contact Limiting Short-Time Current
12A
Protection Category
RTI
Contact Rating
12A
Contact Voltage Rating
240V AC
Contact Limiting Continuous Current
12A
Insulation Creepage
4 mm [ .157 in ]
Insulation Clearance
4 mm [ .157 in ]
Contact Limiting Breaking Current
12A
Switching Voltage
400V AC
Operating Temp. Range
50 to 70°C
Description
