Shop TE CONNECTIVITY

Socket, Power Relay, 5 A, Solder

  • Mfr # 3-1393817-3

  • Zoro # G905865985

product price:
$
301.99
/ea
Free Shipping & Returns

Key Features

Mounting Style
Socket
Electrical Connection
Solder
Coil Voltage
12V DC
Current Rating
5A
Contact Rating (AC)
2 A @ 250V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
3-1393817-3
Zoro #
G905865985
UPC #
-
Country of Origin
Mexico

Details

Item
Power Relay
Mounting Style
Socket
Electrical Connection
Solder
Coil Voltage
12V DC
Current Rating
5A
Contact Rating (AC)
2 A @ 250V
Power Consumption - Relay
1440 mW
Contact Material
Gold F
Number of Poles
2
Features
Bifurcated/Twin Contacts; Standard Type
Contact Limiting Breaking Current
5A
Protection Category
RTI
Dielectric Voltage
1000 Vrms Adjacent Contacts; 1000 Vrms Open Contacts
Operating Temp. Range
-40 to 70 °C
Coil Resistance
100 Ω
Contact Rating
2A
Contact Limiting Short-Time Current
5A
Coil Type
Bistable, 2 Coils, Polarized
Contact Limiting Making Current
5A
Switching Voltage
250 VAC [ 250 VDC ]
Contact Limiting Continuous Current
5A
Contact Voltage Rating
250 VAC [ 250 VDC ]
Contact Form
2 Form C (2 CO)

Description

Power/Signal Relay, 2 Form C, Dpdt, Latched, 0.121A (Coil), 250Vdc (Coil), 1440Mw (Coil), 5A (Contact), 250Vdc (Contact), Ac/Dc Input, Ac/Dc Output, Socket Mount
