Coolant Collet, ER32, 11/16 in.
Mfr # 04546-11/16
Zoro # G9406162
product price:Â
$
74.15
/ea
Key Features
Collet Series
ER32
For Use With
BR Collet Chuck Series, DR Collet Chuck Series, ER Collet Chuck Series, ESX Collet Chuck Series, RD Collet Chuck Series
Coolant Through
Yes
Coolant Fed
Coolant Through
Max. Body Dia.
11/16 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 04546-11/16
- Zoro #
- G9406162
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
- Item
- Collet
- Collet Series
- ER32
- For Use With
- BR Collet Chuck Series, DR Collet Chuck Series, ER Collet Chuck Series, ESX Collet Chuck Series, RD Collet Chuck Series
- Coolant Through
- Yes
- Coolant Fed
- Coolant Through
- Material - Machining
- High Speed Steel
- Measurement System
- Inch
- Collet Type
- Sealed
- Number of Slots
- 6
- Compatible with Product Type
- AR, BR Series, DR, ESX, RD
- Face Shape
- Round
- Features
- No Plugs to Fail, Protects Toolholder from Contaminants, Sealed to 2000 PSI
- Material
- High-Carbon Steel
- Bore Shape
- Round
- Finish
- Precision Ground
- Collapse Range - Maximum
- 0.6875 in
- Operating Pressure - Maximum
- 2,000 psi
- Taper Angle
- 8 Degrees
- Compatible Collet Chuck
- AR, BR, DR, ESX, RD
- T.I.R. Tolerance
- 0.0002 in
- Torque - Maximum
- 100 ft-lb
Description
Collet, ER32, Round, Overall Length 1 9/16 in
