Techniks Spring Collet, ER50, 32mm 04250-32 - main

Spring Collet, ER50, 32mm

  • Mfr # 04250-32

  • Zoro # G0512158

product price:  $73.45
/ea

Key Features

Collet Series
ER50
Range
0 to 100, 0 to 1000
Coolant Through
Yes
For Use With
BR Collet Chuck Series, DR Collet Chuck Series, ER Collet Chuck Series, ESX Collet Chuck Series, RD Collet Chuck Series
Coolant Fed
Coolant Through
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
04250-32
Zoro #
G0512158
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Size
32.0mm
Max. Body Dia.
32.00mm
Overall Length
60 mm
Clamping Hole Length
60 mm
Outside Diameter - Maximum
50 mm

Details

Item
Collet
Collet Series
ER50
Range
0 to 100, 0 to 1000
Coolant Through
Yes
For Use With
BR Collet Chuck Series, DR Collet Chuck Series, ER Collet Chuck Series, ESX Collet Chuck Series, RD Collet Chuck Series
Coolant Fed
Coolant Through
Face Shape
Round
Measurement System
Metric
Number of Slots
8
Collet Type
Standard
TIR Max.
0.0002 in
Compatible with Product Type
AR, BR Series, DR, ESX, RD
Material
High-Carbon Steel
Bore Shape
Round
Torque - Maximum
130 ft-lb
Finish
Precision Ground
Collapse Range - Maximum
32 mm
Taper Angle
8 Degrees
T.I.R. Tolerance
0.0002 in
Operating Pressure - Maximum
2,000 psi
Collapse Range - Minimum
30 mm
Compatible Collet Chuck
AR, BR, DR, ESX, RD

Description

Collet, ER50, Round, Overall Length 60 mm
