Spring Collet, TG100, 1 in.
- Mfr # 04010-1
- Zoro # G0393219
product price:Â
$
30.65
/ea
Key Features
Collet Series
TG100
Range
1" to 0.984"
Coolant Through
Yes
For Use With
TG Collet Chucks
Coolant Fed
Coolant Through
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 04010-1
- Zoro #
- G0393219
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
- Item
- Collet
- Collet Series
- TG100
- Range
- 1" to 0.984"
- Coolant Through
- Yes
- For Use With
- TG Collet Chucks
- Coolant Fed
- Coolant Through
- Number of Slots
- 4
- TIR Max.
- 0.0004 in
- Features
- Up to 750 PSI Coolant
- Collet Type
- Standard
- Measurement System
- Inch
- Face Shape
- Round
- Material
- High-Carbon Steel
- Bore Shape
- Round
- Finish
- Precision Ground
- Collapse Range - Minimum
- 0.9844 in
- Torque - Maximum
- 90 ft-lb
- Collapse Range - Maximum
- 1 in
- T.I.R. Tolerance
- 0.0004 in
- Operating Pressure - Maximum
- 2,000 psi
- Shell Material
- High-Carbon Steel
- Compatible Product Type
- TG Collet Chucks
- Traction Material
- High-Carbon Steel
Dimensions
- Size
- 1"
- Overall Length
- 2 3/8 in
- Min. Size
- 0.9840 in
- Max. Body Dia.
- 1 in
- Head Dia.
- 1.3790 in
- Outside Diameter - Maximum
- 1.379 in
- Clamping Hole Length
- 2 3/8 in
- Wire Rope Length
- 2 3/8 in
- Length
- 2 3/8 in
- Fits Chest Size
- Up to 750 PSI Coolant
- Bottle Size
- 1"
- Size - Alpha
- 1"
- Container Size
- 1"
Description
Collet, TG100, Round, Overall Length 2 3/8 in
