Telemecanique Sensors AC/DC Relay, Universal, Subcompact, 2m Cable XUK0ARCTL2 - main

AC/DC Relay, Universal, Subcompact, 2m Cable

  • Mfr # XUK0ARCTL2

  • Zoro # G0572139

product price: $170.99
/ea
Free Shipping & Returns

Key Features

Depth
50 mm
Material
plastic
Height
50 mm
Width
18 mm
Electrical Connection
cable
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XUK0ARCTL2
Zoro #
G0572139
UPC #
785901510178
Country of Origin
Indonesia

Dimensions

Depth
50 mm
Height
50 mm
Width
18 mm
Cable Length
2 m

Details

Item
Photoelectric Sensor
Material
plastic
Electrical Connection
cable
Status Indicator
No Indicator
Type Of Output Signal
discrete
Product Certifications
CE || UL || CSA
Status Led
1 LED green)supply || 1 LED red)instability || 1 LED yellow)output state
Maximum Sensing Distance
35 m thru beam || 0.28 m diffuse with background suppression || 1.2 m diffuse || 5.7 m polarised reflex
Electrical Durability
500000 cycles 1 60 cyc/mn 250 V
Electronic Sensor Type
photo-electric sensor
Detection System
multimode
Time Delay Range
0 to 10 s monostable, on-delay or off-delay (programmable)
Maximum Delay Response
25 ms
Switching Frequency
<= 20 Hz
Wiring Technique
5-wire
Output Type
relay
[Sn] Nominal Sensing Distance
4-4 m polarised reflex need reflector XUZC50 || 30-30 m thru beam need a transmitter XUK0ARCTL2T || 0.28-0.28 m diffuse with background suppression || 0.8-0.8 m diffuse
Emission
infrared diffuse || infrared diffuse with background suppression || infrared thru beam || red polarised reflex
Shock Resistance
30 gn 11 ms) IEC 60068-2-27
Lens Material
PMMA
Vibration Resistance
7 gn +/- 1.5 mm 10-55 Hz) IEC 60068-2-6
Add On Output
without, <= 50 mA overload and short-circuit protection
Sensor Name
XUK
Supply Voltage Limits
20-264 V AC || 20-264 V DC
Enclosure Material
PBT
[Us] Rated Supply Voltage
24 to 240 V AC || 24 to 240 V DC
Maximum Power Consumption In W
3 W AC/DC
Maximum Delay Recovery
25 ms
Sensor Design
compact 50 x 50
Wire Insulation Material
PvR
Ambient Air Temperature For Operation
-25-55°C
Series Name
general purpose multimode
Discrete Output Function
1 NO or 1 NC programmable
Ambient Air Temperature For Storage
-40-70°C
Setting-Up
self-teaching
Maximum Voltage Drop
<1.5 V closed state)
Supply Circuit Type
AC/DC
Maximum Delay First Up
300 ms
Ip Degree Of Protection
IP65 double insulation IEC 60529
Switching Capacity In Ma
3 A cos φ = 1 for 0.5 million cycles at 1 operating cycle per second at 250 V)
Product Type
Photoelectric Sensor
Includes Indicator Lights
No Indicator Lights Included

Description

Photoelectric Sensor
