Telemecanique Sensors Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, M12, 3 Wires, Shielded XS630B1NAM12 - main

Cylindrical, Inductive Proximity Sensor, 30 mm Dia., Brass, M12, 3 Wires, Shielded

  • Mfr # XS630B1NAM12

  • Zoro # G1170154

product price:  $104.99
/ea
Free Shipping & Returns

Key Features

Style
Cylindrical, Inductive
Measurement Range
8 to 15 mm
Overall Diameter
30 mm
Proximity Sensing Method
Inductive
Body Material
Brass
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
XS630B1NAM12
Zoro #
G1170154
UPC #
785901790259
Country of Origin
Multiple

Dimensions

Overall Diameter
30 mm
Length
72.2 mm
Overall Height
74 mm

Details

Item
Proximity Sensor
Style
Cylindrical, Inductive
Measurement Range
8 to 15 mm
Proximity Sensing Method
Inductive
Body Material
Brass
Proximity Sensor Power Requirement
12 to 48V DC
Electrical Connection
M12
Output Circuit Type
NPN
Output Circuit Number of Wires
3
Sensing Face Shielding
Shielded
Sensing Distance - Maximum
15 mm
AC Voltage Rating
Not Rated
DC Voltage Rating
12-48V DC
Output Circuit Contact Form
NO
Standards
CE, CSA, E2, RoHS, UL Listed
Proximity Sensor Electrical Connection
4 Pin M12 Connector
Proximity Sensor Operating Frequency
500 Hz
Description/Special Features
Extended Range
IP Rating
IP67, IP69K
Operating Temp. Range
-13 Degrees to 158 Degrees F
Max. Current Load
200mA
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Storage Temp. Range
-40-85 °C
Body Type
fixed
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Maximum Delay First Up
10 ms
Maximum Delay Recovery
1.4 ms
Application
mobile equipment; general purpose
Maximum Delay Response
0.6 ms
Series
XS6
Supply Voltage Limits
10-58 V DC
Differential Travel
1...15% of Sr
Maximum Voltage Drop
<2 V closed)
Switching Capacity
<= 200 mA DC overload and short-circuit protection
Includes Indicator Lights
Indicator Lights Included
Load Current - Maximum
200 mA
Operating Temperature - Maximum
158 Degrees F
Operating Temperature - Minimum
-13 Degrees F
Electrical Installation Type
Direct Connector
NEMA Enclosure Rating
4X
Body Finish
Nickel Plated
Number of Pins
4
Switching Frequency
500 Hz
Sensing Distance - Minimum
8 mm
Features
Extended Range

Description

Inductive Cylindrical Proximity Sensor, Inductive, 30 mm, Proximity Sensor Power Requirement 12 to 48V DC, Shielded, Proximity Sensor Operating Frequency 500 Hz, Proximity Sensor Output Circuit Type 3 Wire NPN, Max. Detecting Distance 15 mm, Proximity Sensor Electrical Connection 4 Pin M12 Connector, Output Mode NO, NEMA Rating 4X, IP Rating IP67, IP69K, Case Material Nickel Plated Brass, Length 72.2 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
