  6. Cylindrical Proximity Sensor, 8mm, NPN

This item is Discontinued.

Telemecanique Sensors Cylindrical Proximity Sensor, 8mm, NPN XS508BLNBL2

Cylindrical Proximity Sensor, 8mm, NPN (Discontinued)

  • Mfr # XS508BLNBL2
  • Zoro # G6171636
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
XS508BLNBL2
Zoro #
G6171636
UPC #
-
Country of Origin
France

Dimensions

Length
51 mm
Proximity Sensor Diameter
8 mm
Length (Straight Wireway)
51 mm
Cable Length
2 m
Overall Diameter
8 mm
Overall Height
51 mm

Details

Item
Inductive Cylindrical Proximity Sensor
Proximity Sensor Style
Cylindrical Proximity Sensor
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Proximity Sensor Output Circuit Type
3 Wire NPN
Output Mode
NC
Max. Detecting Distance
1.5 mm
Proximity Sensor Electrical Connection
2m Cable
Basic Proximity Sensor Case Material
Metal
Shielded / Unshielded
Shielded
Proximity Sensor Operating Frequency
2,500 Hz
Case Material
303 Stainless Steel
Max. Current Load
200mA
Operating Temp. Range
-13 Degrees to 158 Degrees F
Description/Special Features
Overload And Short-Circuit Protection, Reverse Polarity, Yellow LED Output Indication
Standards
CE, CSA, RoHS, UL Listed
IP Rating
IP67
Electrical Connection
Bare Wire
Output Circuit Contact Form
NC
Operating Temperature - Maximum
158 Degrees F
Sensing Method
Inductive
Output Circuit Type
NPN
Includes Indicator Lights
Indicator Lights Included
Load Current - Maximum
200 mA
Features
Overload Protection, Reverse Polarity Protection, Short Circuit Protection
Body Stainless Steel Grade
303
Body Finish
Nickel Plated
DC Voltage Rating
12-48V DC
Style
Cylindrical
Sensing Distance - Maximum
2 mm
Series
XS5
Sensing Face Shielding
Shielded
Electrical Installation Type
Prewired Cable
Operating Temperature - Minimum
-13 Degrees F
AC Voltage Rating
Not Rated
Body Material
Stainless Steel
Output Circuit Number of Wires
3
Switching Frequency
5,000 Hz

Description

Inductive Cylindrical Proximity Sensor, Inductive, 8 mm, Proximity Sensor Power Requirement 12 to 48V DC, Shielded, Proximity Sensor Operating Frequency 2,500 Hz, Proximity Sensor Output Circuit Type 3 Wire NPN, Max. Detecting Distance 1.5 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NC, IP Rating IP67, Case Material 303 Stainless Steel, Length 51 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA
