Telemecanique Sensors Heavy Duty Limit Switch, Plunger, 2NC/2NO, 10A at 600V AC, Actuator Location: Top 9007C62E - main
Shop TELEMECANIQUE SENSORS

Heavy Duty Limit Switch, Plunger, 2NC/2NO, 10A at 600V AC, Actuator Location: Top

  • Mfr # 9007C62E

  • Zoro # G1578491

product price:  $269.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007C62E
Zoro #
G1578491
UPC #
785901530817
Country of Origin
Mexico

Dimensions

Body Depth - Limit Switch
1.14 in
Height
4.02"
Depth
1.79"
Width
1.55"
Body Height - Limit Switch
2.5 in
Actuator Length - Limit Switch
0.48 in
Actuator Length
0.48"
Body Width - Limit Switch
0.83 in
Manufacturer Warranty Length
18 mo
Body Width
0.83 in
Overall Height
4.5 in
Overall Depth
1.79 in
Mounting Hole Diameter
0.2 in
Overall Width
1.55 in
Body Height
2.5 in
Body Depth
1.14 in

Details

Item
Heavy Duty Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
DC Contact Rating - Limit Switch
10A at 600V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Actuator Location (Limit Switch)
Top
Mounting Hole Pattern - Limit Switch
2 Hole Diagonal
Electrical Connection
Screw Clamp Terminals
Travel
0.25 in
Operating Force
3.0 lb
Body Material
Zinc
Standards
CSA, UL Listed
Movement
Vertical
Boot Sealed Actuator - Limit Switch
No
Contact Form
2NO/2NC
Actuator Location
Top
Voltage Rating
600VAC/DC
Body Style (Limit Switch)
Miniature
Limit Switch Style
Heavy Duty Limit Switch
AC Contact Rating
10 A @ 600 V
DC Contact Rating
10 A @ 600 V
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
Operating Temp. Range
0 Degrees to 185 Degrees F
Actuator Style
Plunger
Stem Thread - Limit Switch
No Stem
Amps
10
Basic Actuator Style (Limit Switch)
Plunger
Wiring Entry
1/2 in NPT
Contact Form - Limit Switch
2NC/2NO
Actuator Style (Limit Switch)
Plunger
Series
9007C
Boot Sealed Actuator (Limit Switch)
No
Mounting Hole Spacing - Limit Switch
2.35 in x 1.17 in
IP Rating
IP67
Mounting Hole - Limit Switch
(2) 0.20 in dia
Special Features
vertical approach, 1 direction
Head Material
zinc
Contact Material
silver contacts
Mechanical Durability
10000000 cycles
Contact Action
snap action
Weight
1.25 lb(US)
Electrical Durability
1000000 cycles
Vibration Resistance
25 gn 10-150 Hz)IEC 60068-2-6
Shock Resistance
60 gn 9 ms IEC 60068-2-27
Head Type
plunger head
Short Circuit Protection
10 A CC non-time delay
Actuation Type
on end
Directional Movement
Linear
Mounting Hole Vertical Center to Center Distance
60 mm
Mounting Style
Surface
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Mounting Hole Horizontal Center to Center Distance
30 mm
Operating Temperature - Minimum
-20 Degrees F
Boot Sealed Actuator
No Boot Included
Operating Temperature - Maximum
185 Degrees F
Operating Force - Maximum
3 lbf
Resistance Properties
Shock Resistant, Vibration Resistant
Body Configuration
Plug-In
Pretravel
0.08 in
Number of Mounting Holes
2
Type Of Operator
stainless steel spring return plunger
Number Of Poles
2

Description

Plug-In Limit Switch, Actuator Style - Limit Switch Plunger, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 600V, Contact Form- Switches 2NC/2NO, Actuator Length - Limit Switch 0.48 in, Body Height - Limit Switch 2.5 in, Body Width - Limit Switch 0.83 in, Body Depth - Limit Switch 1.14 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6, 6P
