  8. Heavy Duty Limit Switch, Wobble Stick, 2NC/2NO, 10A at 600V AC, Actuator Location: Top
Telemecanique Sensors Heavy Duty Limit Switch, Wobble Stick, 2NC/2NO, 10A at 600V AC, Actuator Location: Top 9007C62KC - main

Heavy Duty Limit Switch, Wobble Stick, 2NC/2NO, 10A at 600V AC, Actuator Location: Top

  • Mfr # 9007C62KC

  • Zoro # G1333647

product price:  $272.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Wobble Stick
Actuator Style - Limit Switch
Wobble Stick
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
9007C62KC
Zoro #
G1333647
UPC #
785901852070
Country of Origin
Mexico

Dimensions

Actuator Length
4.12"
Body Depth - Limit Switch
1.14 in
Height
4.02"
Body Height - Limit Switch
2.5 in
Width
1.55"
Actuator Length - Limit Switch
4.12 in
Depth
1.79"
Body Width - Limit Switch
0.83 in
Mounting Hole Diameter
0.2 in
Body Height
2.5 in
Body Width
0.83 in
Overall Width
1.55 in
Manufacturer Warranty Length
18 mo
Overall Height
8.14 in
Overall Depth
1.79 in
Body Depth
1.14 in

Details

Item
Heavy Duty Limit Switch
Basic Actuator Style - Limit Switch
Wobble Stick
Actuator Style - Limit Switch
Wobble Stick
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
DC Contact Rating - Limit Switch
10A at 600V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Operating Temp. Range
0 Degrees to 185 Degrees F
IP Rating
IP67
Body Style (Limit Switch)
Miniature
Mounting Hole - Limit Switch
(2) 0.20 in dia
Contact Form
2NO/2NC
Limit Switch Style
Heavy Duty Limit Switch
Electrical Connection
Screw Clamp Terminals
Series
9007C
Amps
10
Stem Thread - Limit Switch
No Stem
AC Contact Rating
10 A @ 600 V
Actuator Location
Top
Travel
Total Travel 90 Degrees
Mounting Hole Spacing - Limit Switch
2.35 in x 1.17 in
Contact Form - Limit Switch
2NC/2NO
Movement
Any Direction
Boot Sealed Actuator - Limit Switch
No
Actuator Location (Limit Switch)
Top
Basic Actuator Style (Limit Switch)
Wobble Stick
Voltage Rating
600VAC/DC
Body Material
Zinc
Standards
C22-2-14-95, CE, CSA, EN 60947-1, EN 60947-5-1, IEC 60947, NEMA 250, UL Listed, UL 508
Operating Force
3.0 in-lb
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
Boot Sealed Actuator (Limit Switch)
No
DC Contact Rating
10 A @ 600 V
Mounting Hole Pattern - Limit Switch
2 Hole Diagonal
Actuator Style
Wobble Stick
Actuator Style (Limit Switch)
Wobble Stick
Wiring Entry
1/2 in NPT
Head Material
zinc
Special Features
multi-directional approach, multi-directional approach
Contact Material
silver contacts
Mechanical Durability
10000000 cycles
Electrical Durability
1000000 cycles
Contact Action
snap action
Weight
1.25 lb(US)
Head Type
multi-directional head
Vibration Resistance
25 gn 10-150 Hz)IEC 60068-2-6
Actuation Type
by any moving part
Short Circuit Protection
10 A CC non-time delay
Shock Resistance
60 gn 9 ms IEC 60068-2-27
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Mounting Style
Surface
Pretravel
10 Degrees
Total Travel
90 Degrees
Mounting Hole Vertical Center to Center Distance
60 mm
Operating Temperature - Minimum
-20 Degrees F
Mounting Hole Horizontal Center to Center Distance
30 mm
Operating Torque - Maximum
3 in-lb
Operating Temperature - Maximum
185 Degrees F
Directional Movement
Omnidirectional
Number of Mounting Holes
2
Body Configuration
Plug-In
Boot Sealed Actuator
No Boot Included
Resistance Properties
Shock Resistant, Vibration Resistant
Type Of Operator
steel spring return wobble stick coil spring extension)
Number Of Poles
2

Description

Plug-In Limit Switch, Actuator Style - Limit Switch Wobble Stick, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 600V, Contact Form- Switches 2NC/2NO, Actuator Length - Limit Switch 4.12 in, Body Height - Limit Switch 2.5 in, Body Width - Limit Switch 0.83 in, Body Depth - Limit Switch 1.14 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6, 6P
