  11. Inductive, Rectangular Proximity Sensor, PBT, M12, 3 Wires, Shielded
Telemecanique Sensors Inductive, Rectangular Proximity Sensor, PBT, M12, 3 Wires, Shielded XS8C2A1NCM12 - main

Inductive, Rectangular Proximity Sensor, PBT, M12, 3 Wires, Shielded

  • Mfr # XS8C2A1NCM12

  • Zoro # G3153510

product price: $82.69
/ea
Free Shipping & Returns

Key Features

Measurement Range
0 to 16 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Length
40 mm
Width
70 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
XS8C2A1NCM12
Zoro #
G3153510
UPC #
785901219156
Country of Origin
France

Dimensions

Length
40 mm
Width
70 mm
Depth
40 mm
Overall Width
70 mm
Overall Depth
40 mm
Overall Height
40 mm

Details

Item
Proximity Sensor
Measurement Range
0 to 16 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
12 to 48V DC
Proximity Sensor Electrical Connection
Male Connector M12, 4 Pins
Proximity Sensor Operating Frequency
Less than Or Equal to 300 Hz
Max. Current Load
200mA
IP Rating
IP65, IP67, IP69K
Standards
CCC, CE, CSA, E2, UL Listed
Description/Special Features
5 Positions Turret Head Detection Face; Supply ON 1 LED Green; Output State 1 LED Yellow
Electrical Connection
M12
Operating Temp. Range
-25 to 70 Degrees C
Switching Capacity
<= 200 mA overload and short-circuit protection
Supply Voltage Limits
10-58 V DC
Shock Resistance
50 gn 11 msEN 60068-2-27
Maximum Voltage Drop
<2 V closed)
Body Type
fixed
Application
mobile equipment; general purpose
Storage Temp. Range
-40-85 °C
Series
XS8
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Maximum Delay First Up
7.5 ms
Differential Travel
3...15% of Sr
Maximum Delay Recovery
1.8 ms
Maximum Delay Response
1.2 ms
Number of Pins
4
Sensing Face Shielding
Shielded
Includes Indicator Lights
Indicator Lights Included
Features
Overload Protection, Reverse Polarity Protection, Short Circuit Protection
Switching Frequency
300 Hz
Style
Inductive, Rectangular
Operating Temperature - Maximum
158 Degrees F
Body Material
PBT
Electrical Installation Type
Direct Connector
Output Circuit Number of Wires
3
Operating Temperature - Minimum
-13 Degrees F
AC Voltage Rating
Not Rated
Output Circuit Type
NPN
DC Voltage Rating
12-48V DC
Sensing Distance - Maximum
20 mm
Output Circuit Contact Form
NO/NC

Description

Inductive Rectangular Proximity Sensor, Proximity Sensor Power Requirement 12 to 48V DC, Shielded, Proximity Sensor Output Circuit Type 4 Wire NPN, Output Mode NO/NC, IP Rating IP65, IP67, IP69K, Max. Current Load 200mA, Standards CCC, CE, CSA, E2, UL Listed
