  15. Limit Switch, Cross Roller, Plunger, 1NC/1NO, Actuator Location: Top
Telemecanique Sensors Limit Switch, Cross Roller, Plunger, 1NC/1NO, Actuator Location: Top 9007ML03S0100 - main

Limit Switch, Cross Roller, Plunger, 1NC/1NO, Actuator Location: Top

  • Mfr # 9007ML03S0100

  • Zoro # G0197656

product price: $167.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Cross Roller, Plunger
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Top
Body Style - Limit Switch
Miniature
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007ML03S0100
Zoro #
G0197656
UPC #
785901169420
Country of Origin
Mexico

Dimensions

Body Height - Limit Switch
1.75 in
Width
1.56 in
Body Depth - Limit Switch
0.62 in
Body Height
1.75 in
Overall Depth
0.62 in
Overall Height
1.75 in
Body Depth
0.62 in
Manufacturer Warranty Length
18 mo
Overall Width
1.56 in

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Cross Roller, Plunger
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Top
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Certification
CE, CSA, UL
Mounting Hole Pattern - Limit Switch
2 Hole Horizontal
IP Rating
67
Boot Sealed Actuator - Limit Switch
No
Movement
Linear
Operating Temp. Range
-40 Degrees F to 220 Degrees F
Special Features
Micrometer Adjustable and Low Temperature Operation
Body Material
Cast Zinc
Body Style (Limit Switch)
fixed
Actuator Style
Cross Roller Plunger
Electrical Connection
3 ft Cable, 18 AWG, SJTO
Roller Material
Steel
NEMA Rating
1, 2, 4, 6, 6P
Contact Form
1NO/1NC
Standards
E78403, LR 25490 Class 32 11 03
Contact Material
silver contacts
Series
Miniature potted
Operating Force
80 oz
Arm Material
Metal
Limit Switch Style
Heavy Duty Limit Switch
Actuator Location
Top
Stem Thread - Limit Switch
No Stem
Head Type
plunger head
Mechanical Durability
10000000 cycles
Weight
1.2 lb(US)
Shock Resistance
35 gn 9 ms IEC 60068-2-27
Contact Action
snap action
Actuation Type
by 30° cam
Vibration Resistance
10 gn 75-1200 Hz)IEC 60068-2-6
Electrical Durability
100000 cycles
NEMA Enclosure Rating
1, 2, 4, 6, 6P
Number of Mounting Holes
2
Resistance Properties
Shock Resistant, Vibration Resistant
Operating Temperature - Maximum
220 Degrees F
Operating Force - Maximum
80 ozf
Directional Movement
Linear
Boot Sealed Actuator
No Boot Included
Operating Temperature - Minimum
-40 Degrees F
Mounting Style
Surface
Type Of Operator
spring return cross roller plunger steel
Number Of Poles
1

Description

Limit Switch, Actuator Style - Limit Switch Cross Roller, Plunger, Actuator Location - Limit Switch Top, Contact Form- Switches 1NC/1NO, Body Height - Limit Switch 1.75 in, Body Depth - Limit Switch 0.62 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 2, 4, 6, 6P, Mounting - Limit Switch Surface, Electrical Connection Pre-Wired Cable, IP Rating IP67, Special Features Micrometer Adjustable and Low Temperature Operation
