  15. Limit Switch, Plunger, Roller, SPDT, 10A at 300V AC, Actuator Location: Top
Telemecanique Sensors Limit Switch, Plunger, Roller, SPDT, 10A at 300V AC, Actuator Location: Top 9007MS07S0100 - main

Limit Switch, Plunger, Roller, SPDT, 10A at 300V AC, Actuator Location: Top

  • Mfr # 9007MS07S0100

  • Zoro # G1373766

product price: $161.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 300V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007MS07S0100
Zoro #
G1373766
UPC #
785901319672
Country of Origin
Mexico

Dimensions

Actuator Length - Limit Switch
1.41 in
Height
3.16"
Roller Dia.
0.5 in
Roller Width
0.13 in
Width
1.56"
Body Height - Limit Switch
1.75 in
Actuator Length
1.41"
Body Depth - Limit Switch
0.62 in
Depth
0.62"
Body Width - Limit Switch
1.58 in
Body Depth
0.62 in
Roller Diameter
0.5 in
Overall Depth
0.62 in
Overall Width
1.56 in
Body Width
1.58 in
Mounting Hole Diameter
0.2 in
Overall Height
1.75 in
Body Height
1.75 in
Manufacturer Warranty Length
18 mo

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 300V
DC Contact Rating - Limit Switch
5A at 28V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Stem, Surface
AC Contact Rating
10A at 300V
Operating Force
5.0 in-lb
Contact Form
SPDT
Boot Sealed Actuator (Limit Switch)
No
Voltage Rating
240VAC/28VDC
Mounting Hole Pattern - Limit Switch
2 Hole Horizontal
Body Material
Zinc
Stem Thread - Limit Switch
M14 x 1.00 in
Number of Poles
1
Actuator Style (Limit Switch)
Plunger, Roller
Travel
0.19 in
Boot Sealed Actuator - Limit Switch
No
Mounting Hole Spacing - Limit Switch
0.98 in
Contact Form - Limit Switch
SPDT
Roller Material
Steel
Mounting Hole - Limit Switch
(2) 0.20 in dia
Limit Switch Style
General Purpose Limit Switch
IP Rating
67
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
Operating Temp. Range
-4 Degrees to 221 Degrees F (-20 Degrees to 105 Degrees C)
Wiring Entry
Potted Cable
Series
9007MS
Actuator Location
Top
Amps
10 AC/5 DC
DC Contact Rating
5A at 28V
Actuator Location (Limit Switch)
Top
Standards
CE, CSA, UL
Electrical Connection
3 ft Cable, 4 Wire
Movement
Horizontal
Actuator Style
Parallel Roller Plunger, Thread Mount
Body Style (Limit Switch)
Miniature
Basic Actuator Style (Limit Switch)
Plunger
Contact Material
silver contacts
Certification
CSA || UL || CE
Special Features
lateral approach, 2 directions
Head Type
plunger head
Electrical Durability
100000 cycles
Vibration Resistance
10 gn 75-1200 Hz)IEC 60068-2-6
Shock Resistance
35 gn 9 ms IEC 60068-2-27
Actuation Type
by 30° cam
Contact Action
snap action
Mechanical Durability
10000000 cycles
Weight
1.2 lb(US)
Directional Movement
Linear
Operating Temperature - Maximum
220 Degrees F
Boot Sealed Actuator
No Boot Included
Mounting Style
Stem, Surface
Number of Mounting Holes
2
Resistance Properties
Shock Resistant, Vibration Resistant
Operating Temperature - Minimum
-40 Degrees F
Operating Force - Maximum
80 ozf
Mounting Hole Horizontal Center to Center Distance
25 mm
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Type Of Operator
spring return parallel roller plunger steel bushing mounted

Description

Limit Switch, Actuator Style - Limit Switch Plunger, Roller, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 300V, DC Contact Rating - Limit Switch 5A @ 28V, Contact Form- Switches SPDT, Actuator Length - Limit Switch 1.41 in, Body Height - Limit Switch 1.75 in, Body Width - Limit Switch 1.58 in, Body Depth - Limit Switch 0.62 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6, 6P
