Shop TELEMECANIQUE SENSORS

Pressure Switch, Standard, SPDT, 1 Ports, 1/4-18" FNPT, 5 to 250 psi Range, Aluminum

  • Mfr # 9012GKW6
  • Zoro # G1638621
product price:
$
953.99
/ea
Free Shipping & Returns

Key Features

Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
1
Pressure Connection Type
1/4" FNPT
Range
5 to 250 psi
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
9012GKW6
Zoro #
G1638621
UPC #
785901048763
Country of Origin
Mexico
Item
Pressure Switch
Action
Standard
Contact Form
SPDT
Number of Pressure Connection Ports
1
Pressure Connection Type
1/4" FNPT
Range
5 to 250 psi
Housing Material
Aluminum
Factory On Setting
5 psi
Factory Off Setting
250 psi
Standards
CSA C22.2, UL 508
AC Contact Rating
10A @ 480V
Series
9012G
DC Contact Rating
0.11A @ 250V, 0.22A @ 125V
Actuation Type
Diaphragm
Electrical Connection
Screw-Clamp Terminals
IP Rating
54
Pressure Switch Range
5 to 250 psi
Pressure Switch Port Type
1-Port 1/4-18 in FNPT
Pressure Switch Differential
22 to 110 psi
Pressure Switch Electrical Contact Form
SPDT
Max. Pressure
750 psi
Temp. Range
-10 to 185 °F
Material
Die cast aluminium alloy
Differential Pressure - Minimum
14 psi
Proof Pressure
750 psi
Media Temperature - Minimum
-40 Degrees F
Differential Pressure - Maximum
21 psi
Deadband Adjustability
Fixed
Media Temperature - Maximum
250 Degrees F
Pressure - Minimum
5 psi
Pressure - Maximum
250 psi
Operating Temperature - Maximum
185 Degrees F
Operating Temperature - Minimum
-10 Degrees F
NEMA Enclosure Rating
13, 4, 4X
Actuator Style
Diaphragm

Description

Pressure Switch, NEMA Rating 13, 4, 4X, Series 9012G, Temp. Range -10 Degrees to 185 Degrees F, Standards CSA C22.2, UL 508, Special Features Nitrile (Buna-N) Diaphragm, Control Circuit Rated, Dual Stage Switch, Water Tight, Dust Tight, Oil Tight and Corrosion Resistant (Indoor/Outdoor) Enclosure, AC Contact Rating 3 A @ 240 V, 6 A @ 120 V
