  11. Ultrasonic Label Sensor Npn M8 4P
Telemecanique Sensors Ultrasonic Label Sensor Npn M8 4P XUVU06M3NSNM8 - main

Ultrasonic Label Sensor Npn M8 4P

  • Mfr # XUVU06M3NSNM8

  • Zoro # G0671767

product price: $659.97
/ea
Free Shipping & Returns

Key Features

Electrical Connection
1 male connector M8, 4 pins
Width
18 mm
Depth
47 mm
Height
92.5 mm
Material
metal
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XUVU06M3NSNM8
Zoro #
G0671767
UPC #
-
Country of Origin
France

Dimensions

Width
18 mm
Depth
47 mm
Height
92.5 mm
Passage Depth
69 mm
Minimum Label Length
2 mm
Passage Width
3 mm

Details

Item
Ultrasonic Label Sensor Npn M8 4P
Electrical Connection
1 male connector M8, 4 pins
Material
metal
Accuracy
+/- 0.20 mm 120 m/min
Enclosure Material
zinc alloy
Supply Circuit Type
DC
Status Led
output state 1 LED yellow) || adjustment mode and keypad locking 1 LED red)
Lens Material
PC
Emission
ultrasonic
Sensor Design
fork
[Sn] Nominal Sensing Distance
3-3 mm thru beam
Electronic Sensor Type
photo-electric sensor
Maximum Delay First Up
30 ms
Discrete Output Function
1 NO or 1 NC programmable
Series Name
Application packaging
Sensor Name
XUV
Supply Voltage Limits
10-30 V DC
Minimum Distance Between Labels
2 mm
Detection System
thru beam
Vibration Resistance
7 gn +/- 1.5 mm 10-55 Hz) IEC 60068-2-6
Maximum Delay Response
0.3 ms
[Us] Rated Supply Voltage
12...24 V DC reverse polarity protection
Shock Resistance
30 gn 11 ms) IEC 60068-2-27
Maximum Passing Speed Of Object
180 m/min
Maximum Delay Recovery
0.3 ms
Type Of Output Signal
discrete
Setting-Up
numeric potentiometer
Discrete Output Type
NPN
Maximum Voltage Drop
<2 V closed state)
Ambient Air Temperature For Storage
-20-70°C
Output Type
solid state
Switching Capacity In Ma
<= 100 mA overload and short-circuit protection)
Product Certifications
CE || cULus
Ambient Air Temperature For Operation
5-55°C
Wiring Technique
4-wire
Product Specific Application
detection of transparent labels
Type Of Setting
with
Ip Degree Of Protection
IP65 IEC 60529
Switching Frequency
<= 1500 Hz

Description

Ultrasonic Label Sensor Npn M8 4P
