- MFR #
- TLP615B
- Zoro #
- G5192699
- UPC #
- 037332189820
- Country of Origin
- China
- Item
- Outlet Strip
- Type
- Surge
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- IEEE 587; UL1363; UL1449
- Outlet Surge Protection
- Yes
- Hz
- 60 Hz
- NEMA Receptacle Configuration
- NEMA 5-15R
- Outlet Center Distance
- 28.5 mm
- Number of Outlets
- 6
- Max. Amps
- 15A
- Mounting Style
- Keyhole
- Power Indicator
- Yes
- Number of Transformer Outlets
- 2
- Rated Joules
- 790 J
- Circuit Breaker
- Yes
- Voltage
- 120VAC
- Housing Material
- Plastic
- Number of Outlet Rows
- 1
- Noise Attenuation
- Up to 20 dB
- NEMA Plug Configuration
- NEMA 5-15P
- Coax Surge Protection
- No
- NEC Cord Designation
- 14 ga., SJT
- Frequency
- 60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Package Contents
- Protect It! 6-Outlet Surge Protector, 15 ft. Cord, 790 Joules, Black Housing, Owner's Manual
- Input Voltage
- 120 V AC
- Surge Energy Rating
- 790 J
- Power Handling
- 1875 VA
- Package Includes
- TLP615B Protect It! 6-Outlet Surge Protector, Black Housing;Owner's manual
- Maximum Surge Amps
- 35500
- Diagnostic LED(s)
- Yes
- Overload Protection
- 15A resettable illuminated combo switch / circuit breaker
- AC Suppression Joule Rating
- 790
- Nominal Input Voltage(s) Supported
- 120V AC
- Diagnostic LED Details
- Built-in LED confirms suppressor "protection present" (green) status
- Outlets Measurement (Center to Center)
- 28.5mm
- EMI / RFI Filtering
- Up to 20 dB
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Circuit Breaker (amps)
- 15
- Material of Construction
- Plastic
- AC Suppression Response Time
- < 1 ns
- Mounting Holes or Slots
- Yes
- Frequency Compatibility
- 60 Hz
- Outlet Orientation
- Single row of 6 outlets
- Output Receptacles
- (6) 5-15R
- Input Cord Details
- SJT
- Network (Ethernet) Protection
- No
- Product Type
- Surge Protector Outlet Strip
