- MFR #
- TLP808B
- Zoro #
- G5192680
- UPC #
- 037332189837
- Country of Origin
- China
- Item
- Outlet Strip
- Type
- Surge
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- IEEE 587; UL1363; UL1449
- Outlet Surge Protection
- Yes
- Mounting Style
- Keyhole
- Hz
- 50/60 Hz
- Outlet Center Distance
- 28.5 mm Standard; 57 mm Transformer
- Voltage
- 120VAC
- NEMA Plug Configuration
- NEMA 5-15P
- NEMA Receptacle Configuration
- NEMA 5-15R
- Noise Attenuation
- Up to 40 dB
- Coax Surge Protection
- No
- Number of Transformer Outlets
- 6
- NEC Cord Designation
- 14 ga., SJT
- Max. Amps
- 15A
- Circuit Breaker
- Yes
- Power Indicator
- Yes
- Housing Material
- Plastic
- Number of Outlets
- 8
- Number of Outlet Rows
- 2
- Rated Joules
- 1440 J
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Power Handling
- 1800 VA
- Input Voltage
- 120 V AC
- Package Contents
- Protect It! 8-Outlet Surge Protector, 8 ft. Cord, 1440 Joules, Black Housing, Owner's Manual
- Surge Energy Rating
- 1440 J
- AC Suppression Response Time
- < 1 ns
- Circuit Breaker (amps)
- 15
- Input Cord Details
- SJT
- Outlets Measurement (Center to Center)
- Distance between standard outlets = 28.5mm; Distance between transformer outlets = 57mm
- Outlet Orientation
- Single row of 5, plus a second row of 3 for transformer accommodation
- EMI / RFI Filtering
- Up to 40 dB
- Nominal Input Voltage(s) Supported
- 120V AC
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Frequency Compatibility
- 50 / 60 Hz
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Package Includes
- TLP808B Protect It! 8-Outlet Surge Protector, Black Housing;Owner's manual
- AC Suppression Joule Rating
- 1440
- Input Plug Features
- Right Angle (36D)
- Output Receptacles
- (8) 5-15R
- Diagnostic LED(s)
- Yes
- Outlet Safety Covers Detail
- Includes built-in sliding outlet safety covers
- Material of Construction
- Plastic
- Maximum Surge Amps
- 84000
- Network (Ethernet) Protection
- No
- Mounting Holes or Slots
- Yes
- Product Type
- Surge Protector Outlet Strip
