- Item
- Outlet Strip
- Type
- Surge
- Total Number of Outlets
- 6
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Light Gray
- Gauge/Conductor
- 14/3
- Standards
- Approvals RoHS; UL1449/1363/cUL
- For Use With
- Personal Computers, Stereos and Lamps/Lighting, TV/VCR/DVD
- Circuit Breaker
- 1
- Mounting Style
- Keyhole
- Number of Transformer Outlets
- 2
- NEC Cord Designation
- SJT
- Voltage
- 120VAC
- Coax Surge Protection
- No
- Telephone/Fax Surge Protection
- No
- Max. Surge Current
- 60 kA
- Noise Attenuation
- Up to 20dB
- Max. Amps
- 15A
- Power Indicator
- Yes
- Number of Outlets
- 6
- Outlet Center Distance
- 30.4mm Standard, 45mm Standard and Transformer
- Medical Grade
- No
- Hz
- 50/60 Hz
- Rated Joules
- 1,350
- NEMA Receptacle Configuration
- NEMA 5-15R
- NEMA Plug Configuration
- NEMA 5-15P
- Housing Material
- Metal
- Includes
- Instruction Manual with Warranty Information
- Number of Outlet Rows
- 1
- Outlet Surge Protection
- Yes
- Color - Ext. Cords and Outlet Strips
- White
- NEMA Plug Configuration - Ext. Cords and Outlet Strips
- 5-15P
- Medical Facility Use
- Outside Patient Care Areas (UL 1363)
- Communication Port
- None
- Number of Total Outlets - Ext. Cords and Outlet Strips
- 6
- Gauge/Conductor - Ext. Cords and Outlet Strips
- 14/3
- Max. Amps - Ext. Cords and Outlet Strips
- 15.0
- Number of Conductors
- 3
- Trade Designation
- SJT
- Application
- Commercial and Industrial
- USB Charging Port
- 0
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Power Handling
- 1800 VA
- Output Voltage
- 120 V AC
- Surge Energy Rating
- 1340 J
- Input Voltage
- 120 V AC
- Maximum Line Current
- 15 A
- Certifications & Standards
- UL1449 1998 Rev. (AC Suppression): UL1449, UL1363 (Power Tap): UL1363, UL497A (Communications): UL497A, FCC Part 68 (Communications): FCC Part 68, cUL / CSA (Canada): cUL, Exceeds IEEE 587 category A&B specifications
- Package Contents
- Protect It! TLM626 6-outlets Surge Suppressor, Instruction Manual and Warranty Information
- Compatibility
- VCR, DVD Player, Workstation, Computer, Home Stereos, Televisions
- Mounting Holes or Slots
- Yes
- Maximum Surge Amps
- 60000
- AC Suppression Response Time
- < 1 ns
- EMI / RFI Filtering
- Up to 20 dB
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Nominal Input Voltage(s) Supported
- 120V AC
- AC Suppression Joule Rating
- 1340
- Input Cord Details
- SJT
- Outlet Orientation
- Single row of outlets
- Circuit Breaker (amps)
- 15
- Frequency Compatibility
- 50 / 60 Hz
- Overload Protection
- 15A resettable combo switch / circuit breaker
- Material of Construction
- Metal
- Diagnostic LED(s)
- Yes
- Form Factors Supported
- Supports floor / wall / desktop placement
- Outlets Measurement (Center to Center)
- Distance between standard outlets = 30.40mm; Distance between transformer and standard outlets = 45mm
- Output Receptacles
- (6) 5-15R
- Package Includes
- TLM626 surge suppressor;Instruction manual and warranty information
- Network (Ethernet) Protection
- No
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Product Type
- Surge Protector Outlet Strip
- Maximum Surge Current
- 60 kA
- Plug Style
- Right Angle
- Medical Facility Use UL Rating
- UL 1363
- Rated Energy Absorption
- 1,350 J
- Number of Circuit Breakers
- 1
- Maximum Current
- 15 A
