- Item
- Outlet Strip
- Type
- Surge
- Total Number of Outlets
- 8
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Gray
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); cUL Listed; NOM (Mexico); UL 1449; UL 1363; UL Listed; RoHS
- Hz
- 50/60 Hz
- NEMA Plug Configuration
- NEMA 5-15P
- Mounting Style
- Keyhole
- Includes
- Instruction Manual with Warranty Information
- Rated Joules
- 1,440
- NEMA Receptacle Configuration
- NEMA 5-15R
- Max. Amps
- 15A
- Noise Attenuation
- Up to 40dB
- Coax Surge Protection
- No
- Outlet Center Distance
- 28.5mm Standard and 57mm Transformer
- Power Indicator
- Yes
- Circuit Breaker
- 1
- Number of Transformer Outlets
- 3
- Max. Surge Current
- 84 kA
- Voltage
- 120VAC
- NEC Cord Designation
- SJT
- Housing Material
- Plastic
- Telephone/Fax Surge Protection
- No
- For Use With
- Desktop, Network Or Home Computing Application Requiring AC Protection
- Number of Outlets
- 8
- Medical Grade
- No
- Outlet Surge Protection
- Yes
- Medical Facility Use
- Outside Patient Care Areas (UL 1363)
- Number of Outlet Rows
- 2
- Number of Total Outlets - Ext. Cords and Outlet Strips
- 8
- Gauge/Conductor - Ext. Cords and Outlet Strips
- 14/3
- Communication Port
- None
- Max. Amps - Ext. Cords and Outlet Strips
- 15.0
- NEMA Plug Configuration - Ext. Cords and Outlet Strips
- 5-15P
- Color - Ext. Cords and Outlet Strips
- Gray
- Application
- Home; Office
- Trade Designation
- SJT
- USB Charging Port
- 0
- Number of Conductors
- 3
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Compatibility
- Workstation, Desktop PCs, Telecom System
- Maximum Line Current
- 15 A
- Surge Energy Rating
- 1440 J
- Certifications & Standards
- UL1449 (let through rating 330V), IEEE 587 Category A and B, UL1363, cUL
- Power Handling
- 1800 VA
- Output Voltage
- 120 V AC
- Package Contents
- Protect It! 8-Outlets Surge Suppressor, Instruction Manual with Warranty Information
- Input Voltage
- 120 V AC
- Circuit Breaker (amps)
- 15
- Input Cord Details
- SJT
- Output Receptacles
- (8) 5-15R
- Material of Construction
- Plastic
- Mounting Holes or Slots
- Yes
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Frequency Compatibility
- 50 / 60 Hz
- AC Suppression Joule Rating
- 1440
- Nominal Input Voltage(s) Supported
- 120V AC
- Diagnostic LED(s)
- Yes
- EMI / RFI Filtering
- Up to 40 dB
- Network (Ethernet) Protection
- No
- Package Includes
- TLP808 Protect It! 8-Outlet Surge Protector, Light Gray Housing;Owner's manual
- Outlets Measurement (Center to Center)
- Distance between standard outlets = 28.5mm; Distance between transformer outlets = 57mm
- Maximum Surge Amps
- 84000
- Input Plug Features
- Right Angle (36D)
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
- Outlet Safety Covers Detail
- Includes built-in sliding outlet safety covers
- AC Suppression Response Time
- < 1 ns
- Outlet Orientation
- Single row of 5, plus a second row of 3 for transformer accommodation
- Medical Facility Use UL Rating
- UL 1363
- Rated Energy Absorption
- 1,440 J
- Plug Style
- Straight
- Product Type
- Surge Protector Outlet Strip
- Number of Circuit Breakers
- 1
- Maximum Current
- 15 A
- Maximum Surge Current
- 84 kA
