- Item
- PDU
- Type
- Monitored
- Receptacle Configuration
- (42) C13, (6) C19
- Plug Configuration
- IEC-60309 60A BLUE (3P+E)
- Standards
- RoHS Compliant; TAA Compliant
- Max. Amps
- 35A
- Housing Material
- Metal
- Power Indicator
- Yes
- NEMA Receptacle Configuration
- (42) C13; (6) C19
- NEMA Plug Configuration
- IEC-309 60A BLUE (3P+E)
- Voltage
- 200/208/240V
- Number of Outlets
- 48
- Mounting Style
- Vertical Rackmount/0U
- Frequency
- 50/60 Hz
- Package Contents
- Monitored PDU3VN3G60 36-Outlets 12.6kW PDU, Cord Retention Brackets, Rack Mounting Brackets, Owner's Manual
- Power Rating (Watt)
- 12.60 kW
- Output Voltage
- 208 V AC
- Receptacle Detail
- 6 x IEC 60320 C19, 30 x IEC 60320 C13
- Product Type
- PDU
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Input Voltage
- 230 V AC
- PDU Type
- Monitored
- Frequency Compatibility
- 50 / 60 Hz
- PDU Form Factor
- Vertical (0U)
- Network Compatibility
- 10 Mbps; 100 Mbps (Fast Ethernet)
- Front Panel LEDs
Set of 6 LEDs identify the value displayed on the large digital display: Amperage (A), Kilowatts (kW), Voltage (V), Unbalance percentage (%UB), Temperature (T), Humidity (%RH); One additional LED for each output load bank (B1-B3) offers information power availability: GREEN (<80% load), YELLOW (>80% load), RED (Power OFF), RED FLASHING (Power OFF/breaker trip)
- Input Phase
- 3-Phase
- Overload Protection
- 3 20A circuit breakers, 1 per outlet bank
- Form Factors Supported
- Vertical rackmount installation supported with included mounting brackets; supports toolless mounting in button-mount compatible racks
- Power Measurement Accuracy (Watts)
- +/-1%
- Maximum Input Amps
- 35
- Current Measurement Accuracy (Amps)
- +/-1%
- Input Cord Details
- Cord length specifications are nominal and subject to manufacturing variance
- Operating Elevation (ft.)
- 0-10,000
- Output Nominal Voltage
- 200; 208; 240
- Operating Temperature Range
- 32 to 122F (0 to 50C)
- Package Includes
- PDU3VN3G60 14.5kW 200/208/240V 3-Phase Monitored PDU, 3 ft. cord;(42) C13/C14 plug-lock inserts;(6) C19/C20 plug-lock inserts;Spare mounting buttons;(2) Conventional mounting brackets;Configuration cable for network interface;Button/bracket-mounting hardware;Owner's manual
- Material of Construction
- Metal
- Reported Load Segments
Reports input current per phase (L1, L2, L3) and output current for each breakered load bank (20A balanced max per banks B1-B3); Outlets are color-coded and labeled for phase and load bank identification; L1-L2 feeds black outlets (B1); L2-L3 feeds dark-gray outlets (B2); L3-L1 feeds light-gray outlets (B3)
- Output Receptacles
- (42) C13; (6) C19
- Output Capacity Details
- 14.5kW (240V), 13.9kW (230V), 13.3kW (220V), 12.6kW (208V), 12.1kW (200V) total capacity; 20A max per breakered outlet bank; 16A max per C19 outlet; 12A max per C13 outlet
- Communications Cable
- RJ45-to-DB9 configuration/console Access cable
- Storage Temperature Range
- 5 to 140F (-15 to 60C)
- Front Panel LCD Display
Large digital display reports Amperage, Kilowatts, Voltage, Unbalance percentage, Temperature* and Humidity* information (*requires ENIVIROSENSE option); Small digital display provides detail on the measurement the large display is reporting: Input-phase (L#), Load bank (B#), Sensor (S#), Load unbalance (UB), Output power (OP)
