- Item
- PDU
- Type
- Switched
- Receptacle Configuration
- C13
- Plug Configuration
- IEC-320 C14
- Standards
- UL/CAN 60950-1; FCC / EN Class A; NOM; CE (IEC 60950); TAA Compliant
- Max. Amps
- 15A
- Mounting Style
- Horizontal Rackmount/1U
- Hz
- 50/60 Hz
- Housing Material
- Metal
- Includes
- Mounting Accessories
- Phase
- 1
- Voltage
- 200/240V
- Metered
- Yes
- Number of Outlets
- 8
- NEMA Plug Configuration
- IEC-320 C14
- NEMA Receptacle Configuration
- C13
- Frequency
- 50/60 Hz
- Features
- Digital Display
- Watts
- 2.5kW (208V), 2.3kW (230V)
- Package Contents
- PDUMH15HVNET PDU Switched 208V - 240V 15A 8 Outlet, Rackmount PDU, Rack mounting brackets
- Input Voltage Range
- 208 V AC - 240 V AC
- Output Voltage
- 240 V AC, 208 V AC
- PDU Type
- Switched
- Product Type
- PDU
- Mount Type
- Rack-mountable
- Network (RJ-45)
- Yes
- Input Voltage
- 230 V AC
- Receptacle Detail
- 8 x IEC 60320 C13
- PDU Form Factor
- Horizontal (1U)
- Output Nominal Voltage
- 208/230V
- PDU Input Voltage
- 208; 230
- Storage Temperature Range
- -22° to 122°F (-30° to 50°C)
- Network Monitoring Port
- RJ45 Network port, Micro-USB Configuration port, USB A port supports a variety of Envirosense2 environmental and control modules. See Accessories>Management Hardware section for more information about these modules.
- Network Compatibility
- 10 Mbps; 100 Mbps (Fast Ethernet)
- Communications Cable
- Micro-USB- to-USB A configuration/console Access cable
- Input Phase
- Single-Phase
- Output Receptacles
- (8) C13
- Material of Construction
- Metal
- Input Connection Type
- C14 inlet
- Grounding
- Back panel grounding lug
- Front Panel LEDs
- 8 LEDs display power on-off status for each output receptacle
- Package Includes
- 1U Switched PDU;Mounting brackets;Cord retention plates;C13 to C14 power cable
- Output Capacity Details
- 2.5kW (208V), 2.3kW (230V) / 12A (10A CE) total capacity
- Front Panel LCD Display
- Digital display reports total PDU output current in amps
- Customized Load Management Receptacles
- 8 individually switched output receptacles
- High Availability PDU Features
- Auto Probe Monitoring and Reboot (included); Auto Load Shedding
- Form Factors Supported
- 1U rackmount, Includes mounting accessories for 2-4 post racks
- Frequency Compatibility
- 50 / 60 Hz
- Operating Temperature Range
- 32° to 104°F (0° to 40°C)
- Maximum Input Amps
- 12
- Operating Elevation (ft.)
- 0-10,000
