- Type
- Surge
- Number of Outlets
- 12
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Display Type
- No Display
- Item
- Power Strip
- Footnotes
- 4,6,9
- Includes
- USB Cables
- NEMA Plug Configuration
- 5-15p
- Input Voltage - UPS Systems
- 120V AC
- Watts
- 450W
- Outlet Type
- (6) Surge, (6) UPS/Surge
- Mounting
- Desktop, Tower, Wall
- Ports
- USB (HID enabled)
- Input Current
- 10 A
- Mounting - UPS Systems
- Desktop/Tower
- Automatic Volts Regulation
- No
- Watts - UPS Systems
- 450.0 W
- Power Rating
- 750VA
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- VA Rating - UPS Systems
- 750.0 VA
- Transfer Time
- 3 msec from Battery to AC, 6 msec from AC to Battery
- NEMA Receptacle Configuration
- 5-15R
- Medical Grade
- Not Medical Grade Approved
- Backup Time (Half/Full Load)
- 11.5 min/2.5 min
- Special Features
- (4) Built-In ECO Outlets w/Auto Off, Poweralert Software
- Input Voltage
- 120 V AC
- Hz
- 60 Hz
- Phase
- Single
- Output Voltage
- 110 V, 115 V, 120 V
- Standards
- CSA, FCC Part 15 Class B, NOM, RoHS, UL1778
- UPS Type
- Standby
- Output Voltage - UPS Systems
- 115V AC, 120V AC
- Fax/Modem Line Protection
- Yes
- Outlet Type - UPS Systems
- (6) Surge, (6) UPS/Surge
- Green Certification or Other Recognition
- UL 1778CSAFCC Part 15 Category B (EMI)TAA, RoHS
- Wattage
- 450 W
- Voltage
- 120
- Capacity - Batteries
- 750 VA/450 W
- Input Connection
- 6 ft Cord with NEMA 5-15P Plug
- Housing Material
- Plastic
- DC System Voltage (VDC)
- 12
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Network UPS Tools Compatibility
- NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
- Half Load Runtime (min.)
- 9.4 min. (225w)
- Input Phase
- Single-Phase
- Communications Cable
- USB interface cable included
- Frequency Compatibility
- 60 Hz
- UPS AC Suppression Response Time
- Instantaneous
- Expandable Runtime
- No
- Nominal Voltage Details
- 115v nominal output in battery mode
- Installation Form Factors Supported with Included Accessories
- Tower; Ultra-compact desktop; Wallmount
- Low Voltage Transfer to Battery Power (Setpoint)
- 99
- Nominal Input Voltage(s) Supported
- 120V AC
- UPS AC Suppression Joule Rating
- 420
- LED Indicators
- 3 LEDs indicate power status, overload/check battery and ECO-mode status
- UPS Dataline Suppression
- 1 line TEL/DSL (1 in / 1 out)
- Output AC Waveform (AC Mode)
- Sine wave
- Communications Interface
- USB (HID enabled)
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Output Volt Amp Capacity (VA)
- 750
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- EMI / RFI AC Noise Suppression
- Yes
- Individually Controllable Load Banks
- No
- Output Watt Capacity (Watts)
- 450
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Output Receptacles
- (12) 5-15R
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- Battery Recharge Rate (Included Batteries)
- Less than 16 hours from 10% to 90%
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- High Voltage Transfer to Battery Power (Setpoint)
- 139
- UPS Output Receptacles (Surge Suppression Only)
- 6 UPS outlets, 6 surge-only outlets
- USB
- Yes
- Typical Battery Recharge Time
- 20 Hour
- Dataline Protection
- RJ-11
- Receptacle Detail
- 6 x NEMA 5-15R
- Load Capacity
- 750 VA/450 W
- Certifications & Standards
- UL 1778, CSA, FCC Part 15 Category B (EMI), TAA
- Product Type
- Standby UPS
- Package Contents
- ECO750UPSTAA 750 VA Desktop UPS, USB Cable, Instructional Manual with Warranty Information
- Form Factor
- Desktop
- High Availability UPS Features
- Surge/noise protection
- Output Capacity (Watts)
- 450
- Output Capacity (VA)
- 750
- UPS Applications
- Computer/Peripherals
- Package Includes
- ECO750UPSTAA TAA Compliant UPS System;USB cable;Instruction manual
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Visible Indicator Light Conditions
- Overload, Power Status
- Number of Outlets - Surge Only
- 6
- Run Time - Full Load
- 2.8 min
- External Battery Compatible
- Not External Battery Pack Compatible
- Number of Outlets - UPS
- 6
- Battery Recharge Time
- 16 hr
- Input Current - Maximum
- 10 A
- Battery Chemistry
- Valve Regulated Lead Acid
- Transfer Time - Maximum
- 4 msec
- Frequency
- 60 Hz
- Includes Battery
- Battery Included
- Operating Temperature - Minimum
- 32 Degrees F
- Operating Temperature - Maximum
- 104 Degrees F
- Data Line Protection
- Includes Data Line Surge Protection
- Output Ports Included
- USB
- Power Rating - Real
- 450 W
- Manufacturer Warranty
- 3 yr Limited
- Power Rating - Apparent
- 750 VA
- Run Time - Half Load
- 9.4 min
- Audible Alarm Conditions
- Overload
- Transfer Time - Minimum
- 1 msec
