- MFR #
- TLP606RNET
- Zoro #
- G6212936
- UPC #
- 037332178244
- Country of Origin
- China
- Item
- Power Strip
- Type
- Surge
- Total Number of Outlets
- 6
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); CAN/CSA-C22.2 No. 42 (Canada); cUL Listed; UL 1449; UL 498; UL 1363; UL Listed; RoHS
- Power Indicator
- Yes
- Footnotes
- 2,3,8
- Hz
- 50/60 Hz
- Voltage
- 120VAC
- Number of Total Outlets - Ext. Cords and Outlet Strips
- 6
- Includes
- Line Rotating Gold Coaxial, Line Telephone/Modem Protection
- Number of Outlets
- 6
- Circuit Breaker
- 1
- Max. Amps - Ext. Cords and Outlet Strips
- 15.0
- Max. Amps
- 15A
- Color - Ext. Cords and Outlet Strips
- Black
- NEMA Plug Configuration - Ext. Cords and Outlet Strips
- 5-15P
- Mounting Style
- Keyhole
- Housing Material
- Plastic
- Medical Grade
- No
- Number of Transformer Outlets
- 0
- For Use With
- Small Home/Business, Theater Installations
- Green Environmental Attribute
- RoHS 2011/65/EU Compliant
- Rated Joules
- 1,440
- Gauge/Conductor - Ext. Cords and Outlet Strips
- 14/3
- GFCI Protected
- No
- NEMA Plug Configuration
- NEMA 5-15P
- Communication Port
- (2) Coaxial, (2) RJ11 Telephone
- Telephone/Fax Surge Protection
- Yes
- NEMA Receptacle Configuration
- NEMA 5-15R
- Coax Surge Protection
- Yes
- NEC Cord Designation
- 14 ga., SJT
- Max. Surge Current
- Not Rated
- Medical Facility Use
- Outside Patient Care Areas (UL 1449)
- Outlet Surge Protection
- Yes
- Number of Conductors
- 3
- USB Charging Port
- 0
- Application
- Home; Office
- Frequency
- 60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Rotatable Outlets
- Watts
- 1800W
- Surge Energy Rating
- 1440 J
- Dataline Protection
- Phone/DSL, Network, Coaxial Cable Line
- Input Voltage
- 120 V AC
- Package Contents
- TLP606RNET Surge Suppressor, Instruction Manual with Warranty Information, 6 ft. Gold Coaxial Cable, 6 ft. Phone Cord, 6 ft Network Cord
- Cable (Coax) Protection
- Yes
- AC Suppression Joule Rating
- 1440
- AC Suppression Response Time
- < 1 ns
- Frequency Compatibility
- 60 Hz
- Circuit Breaker (amps)
- 15
- Package Includes
- TLP606RNET 6-Outlet Surge Protector, Black;Gold coaxial cable, 6 ft. (1.8 m);Telephone cable, 6 ft.;Ethernet network cable, 6 ft.;Owner's manual
- Network (Ethernet) Protection
- Yes
- Diagnostic LED(s)
- Yes
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Network Compatibility
- 100 Mbps (Fast Ethernet)
- Nominal Input Voltage(s) Supported
- 120V AC
- Mounting Holes or Slots
- No
- Input Cord Details
- SJT
- EMI / RFI Filtering
- 150 kHz to 100 mHz
- Output Receptacles
- (6) 5-15R
- Input Plug Features
- Right Angle (90D)
- Outlet Orientation
- Rotatable
- Diagnostic LED Details
- Built-in LEDs confirm suppressor "protected" (green) and "grounded" (red) status
- Material of Construction
- Plastic
- Number of Circuit Breakers
- 1
- Medical Facility Use UL Rating
- UL 1449
- Plug Style
- Right Angle
- Product Type
- Surge Protector Outlet Strip
- Rated Energy Absorption
- 1,440 J
- Maximum Surge Current
- Not Rated
- Maximum Current
- 15 A
