- MFR #
- TLP606USBBTAA
- Zoro #
- G5175436
- UPC #
- 037332183088
- Country of Origin
- China
- Item
- Power Strip
- Type
- Surge, USB
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); cUL Listed; NOM (Mexico); UL 1449; UL 1363; UL Listed; RoHS; Trade Agreements Act (TAA)
- Voltage
- 120VAC
- Circuit Breaker
- Yes
- Coax Surge Protection
- No
- Housing Material
- Plastic
- Power Indicator
- Yes
- Outlet Center Distance
- 28.5 mm
- NEMA Receptacle Configuration
- NEMA 5-15R
- Mounting Style
- Keyhole
- NEMA Plug Configuration
- NEMA 5-15P
- Number of Outlet Rows
- 1
- Max. Amps
- 15A
- Number of Transformer Outlets
- 2
- Outlet Surge Protection
- Yes
- Rated Joules
- 990 J
- NEC Cord Designation
- 14 ga., SJT
- Hz
- 50/60 Hz
- Number of Outlets
- 2 USB/6
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Maximum Line Current
- 2.10 A
- Input Voltage
- 120 V AC
- Compatibility
- Workstations, Desktop Pcs, Telecom Systems
- Surge Energy Rating
- 990 J
- Product Type
- Surge Suppressor/Protector
- Maximum Surge Current
- 35.5 kA
- Package Contents
- TAA Complaint Protect It! Surge Suppressor, Instruction Manual with Warranty Information
- Power Handling
- 1875 VA
- Output Voltage
- 5 V DC
- Mounting Holes or Slots
- Yes
- Outlet Orientation
- Single row of 6 outlets
- Charging Port Type
- USB A (FEMALE)
- Maximum Surge Amps
- 35500
- Diagnostic LED(s)
- Yes
- Overload Protection
- 15A resettable illuminated combo switch / circuit breaker
- Nominal Input Voltage(s) Supported
- 120V AC
- Circuit Breaker (amps)
- 15
- Charging Method
- USB
- Material of Construction
- Plastic
- Charging Ports / Amps
- (2) 2.1A
- Output Receptacles
- (6) 5-15R
- AC Suppression Joule Rating
- 990
- Outlets Measurement (Center to Center)
- 28.5mm
- Network (Ethernet) Protection
- No
- Input Cord Details
- SJT
- Device Compatibility
- Phone; Tablet; Amazon Kindle
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- AC Suppression Response Time
- < 1 ns
- Number of Charging Ports
- 2
- Package Includes
- TLP606USBBTAA surge suppressor;Instruction manual with warranty information
- Charging Form Factor
- Strip
- Frequency Compatibility
- 50 / 60 Hz
- Outlet Spacing
- 1.122-in. center-to-center spacing
- Diagnostic LED Details
- Built-in LED confirms suppressor "protection present" (green) status
- EMI / RFI Filtering
- Yes
- Form Factor Details
- Strip
