- MFR #
- TLP606DMUSB
- Zoro #
- G6220243
- UPC #
- 037332180292
- Country of Origin
- China
- Item
- Power Strip
- Type
- Surge, USB
- Total Number of Outlets
- 6
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Black
- Gauge/Conductor
- 14/3
- Standards
- CAN/CSA-C22.2 No. 269.3 (Canada); CAN/CSA-C22.2 No. 308 (Canada); CAN/CSA-C22.2 No. 42 (Canada); cUL Listed; UL 1449; UL 498; UL 1363; UL Listed; RoHS
- GFCI Protected
- No
- Power Indicator
- Yes
- For Use With
- Charging Ports for Portable Devices, Desktop, Home Computing, Network
- Rated Joules
- 2,100
- Color - Ext. Cords and Outlet Strips
- Black
- Max. Amps - Ext. Cords and Outlet Strips
- 15.0
- Max. Surge Current
- 35.5 kA
- NEMA Plug Configuration - Ext. Cords and Outlet Strips
- 5-15P
- Green Environmental Attribute
- RoHS 2011/65/EU Compliant
- Number of Transformer Outlets
- 2
- Footnotes
- 21
- Medical Grade
- No
- Housing Material
- Plastic
- Mounting Style
- Clamp
- NEMA Receptacle Configuration
- NEMA 5-15R
- Includes
- Dual 2.1A USB Ports
- Number of Outlets
- 2 USB/6
- Gauge/Conductor - Ext. Cords and Outlet Strips
- 14/3
- Number of Total Outlets - Ext. Cords and Outlet Strips
- 6
- Voltage
- 120VAC
- Hz
- 50/60 Hz
- Coax Surge Protection
- No
- Circuit Breaker
- 1
- NEMA Plug Configuration
- NEMA 5-15P
- Max. Amps
- 15A
- Telephone/Fax Surge Protection
- No
- Communication Port
- None
- Medical Facility Use
- Outside Patient Care Areas (UL 1449)
- Outlet Surge Protection
- Yes
- NEC Cord Designation
- 14 ga., SJT
- Number of Outlet Rows
- 1
- Special Features
- 2.1A Each USB Charging Ports
- Application
- Home; Office
- Number of Conductors
- 3
- USB Charging Port
- 2
- Frequency
- 50/60 Hz
- Features
- Automatic Shut-Off, Diagnostic LED(s)
- Watts
- 1800W
- Surge Energy Rating
- 2100 J
- Input Voltage
- 120 V AC
- Compatibility
- Smartphones, Tablet PC's, MP3 Players
- Output Voltage
- 5 V DC
- Package Contents
- Protect It! TLP606DMUSB 6-Outlets Surge Suppressor, Instruction Manual with Warranty Information
- Dataline Protection
- USB
- Maximum Surge Current
- 35.5 kA
- Power Handling
- 1875 VA
- Certifications & Standards
- UL Listed Certification
- Overload Protection
- 15A resettable illuminated combo switch / circuit breaker
- Charging Form Factor
- Strip
- Nominal Input Voltage(s) Supported
- 120V AC
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Number of Charging Ports
- 2
- Diagnostic LED Details
- Built-in LED confirms suppressor "protection present" (green) status
- Device Compatibility
- Phone; Tablet; Amazon Kindle
- Material of Construction
- Plastic
- Input Cord Details
- SJT
- Charging Method
- USB
- Mounting Holes or Slots
- No
- AC Suppression Joule Rating
- 2100
- Diagnostic LED(s)
- Yes
- Network (Ethernet) Protection
- No
- EMI / RFI Filtering
- Yes
- Charging Ports / Amps
- (2) 2.1A
- Charging Port Type
- USB A (FEMALE)
- Maximum Surge Amps
- 35500
- Circuit Breaker (amps)
- 15
- Output Receptacles
- (6) 5-15R
- Outlet Orientation
- Single row of 6 outlets
- AC Suppression Response Time
- < 1 ns
- Package Includes
- TLP606DMUSB surge suppressor;Instruction manual with warranty information
- Frequency Compatibility
- 50 / 60 Hz
- Number of Circuit Breakers
- 1
- Medical Facility Use UL Rating
- UL 1449
- Plug Style
- Right Angle
- Rated Energy Absorption
- 2,100 J
- Maximum Current
- 15 A
- Product Type
- Surge Protector Outlet Strip
