VA Rating - UPS Systems
500.0 VA
UPS Type
Line Interactive
Backup Time (Half/Full Load)
14 min/3 min
Outlet Type
(1) Surge; (6) UPS/Surge
Special Features
Advanced AVR Corrects Brownouts and Overvoltages, Pure Sine Wave Output
Standards
CSA (Canada), ENERGY STAR Qualified, FCC Part 15 Class B (USA), ICES (Canada), NOM (Mexico), RoHS, UL1778
Automatic Volts Regulation
Yes
NEMA Receptacle Configuration
(6) 5-15R
NEMA Plug Configuration
5-15P
Fax/Modem Line Protection
No
Ports
DB9 Serial, EPO, SNMP/Web Slot, USB (HID Enabled)
Transfer Time
4 to 6 msec
Includes
Cables for USB and DB9 Monitoring and EPO Switching, Mounting Hardware, PowerAlert Unattended Shutdown and UPS/Power Monitoring Software
Capacity - Batteries
500 VA/300 W
Battery Type
Sealed Lead Acid (SLA)
Operating Temp. Range
122°F (50°C)
Input Connection
10 ft Cord with NEMA 5-15P Plug
AC Suppression Joule Rating
567
Half Load Runtime (min.)
14.6 min. (150w)
Alarm Cancel Operation
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
AC Mode BTU / Hr. (Full Load)
44
Individually Controllable Load Banks
Yes
EMI / RFI AC Noise Suppression
Yes
Nominal Output Voltage(s) Supported
110V; 115V; 120V
Grounding Lug
Back panel grounding lug
Input Circuit Breakers
15A
Output Volt Amp Capacity (VA)
500
Included Mounting Accessory Description
Included mounting brackets provide front-rail installation in 2 or 4 post racks, plus upright tower configurations
DC System Voltage (VDC)
12
Undervoltage Correction
Input voltages between 90 and 105 are boosted by 14%
Internal UPS Replacement Battery Cartridge
RBC62-1U
Output Voltage Regulation (Battery Mode)
+/- 5%
Battery Recharge Rate (Included Batteries)
Less than 16 hours from 10% to 90% (typical, full load discharge)
Output AC Waveform (Battery Mode)
PWM sine wave
High Availability UPS Features
Hot swappable batteries
High Voltage Transfer to Battery Power (Setpoint)
140
Recommended Electrical Service
15A 120V
Switches
2 Switches control off/on power status and alarm-cancel/self-test operation
Audible Noise
45 dBA maximum, front side 1m
UPS Certifications
Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico)
Installation Form Factors Supported with Included Accessories
2 post 19 inch rackmount; 4 post 19 inch rackmount; Tower
Low Voltage Transfer to Battery Power (Setpoint)
90
Rated input current (Maximum Load)
12A (Maximum input with 300W UPS and 1140W surge-only loads)
AC Mode Efficiency Rating (100% Load)
0.96
Audible Alarm
Audible alarm indicates power-failure, overload and low-battery conditions
Primary Form Factor
Rackmount
Voltage Regulation Description
Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 90
Full Load Runtime (min.)
3.2 min. (300w)
Communications Cable
USB and DB9 cabling included
Output Watt Capacity (Watts)
300
Network Management Cards
SNMPWEBCARD ; TLNETCARD ; WEBCARDLX
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
Network UPS Tools Compatibility
NUT compatible. See full list of compatible Tripp Lite products at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
Battery Access
Battery access door
Relative Humidity
0 to 95%, non-condensing
PowerAlert Software
For local monitoring via the UPSâ„¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
LED Indicators
5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status
Network Monitoring Port Description
Supports detailed monitoring of UPS and site power conditions
Output Voltage Regulation (Line Mode)
-15%, +13%
Load Management Receptacles
One switchable single-outlet 5-15R load bank
AC Suppression Response Time
Instantaneous
Storage Temperature Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Battery Replacement Description
Hot-swappable, user replaceable batteries
Communications Interface
USB (HID enabled); DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Nominal Input Voltage(s) Supported
120V AC
Surge Energy Rating
480 J
Maximum Operating Temperature
122°F (50°C)
Network Management
SNMP Manageable
Status Indicators
5 front panel LEDs - Green POWER LED, 3 color BATTERY CHARGE LED, 3 color OUTPUT LOAD LEVEL LED, red BATTERY WARNING LED.
Waveform Type
Pulse-width Modulated Sine Wave
Battery Chemistry
Valve Regulated Lead Acid
Typical Battery Recharge Time
4 Hour
Software Included
PowerAlert Software
Load Capacity
500 VA/300 W
Package Contents
SMART500RT1U UPS System, Mounting hardware, Cabling for USB & DB9 monitoring and EPO switching, PowerAlert unattended shutdown and UPS/Power monitoring software, Warranty information and instruction manual
Alarm
Low Battery, Overload, UPS Fault, On Battery
Total Number of Expansion Slots
4
UPS Applications
High-End Desktop/Small Network; Retail/Point of Sale; Hospitality
Operating Elevation (ft.)
6561 ft. (2000 m) above sea level
Frequency Compatibility Details
Output is regulated to +/-0.05Hz when input frequency exceeds +/-5Hz of nominal.
Output Capacity Details
4.2A @ 120V. (LINE MODE) 120% @ 5 minutes; (BATTERY MODE) 120% @ 5 seconds
Output Capacity (Watts)
300
Package Includes
SMART500RT1U 500VA 300W 120V Line-Interactive UPS;USB cable;DB9 cable;EPO cable;Rack-mounting hardware;Owner's manual
AC Economy Mode Efficiency Rating (100% Load)
0.97
Product Compliance
ENERGY STAR Qualified
Grounding Details
Back panel grounding lug
Product Certifications
CSA (Canada); NOM (Mexico); UL 1778
Operating Temperature - Maximum
104 Degrees F
Transfer Time - Minimum
1 msec
Run Time - Full Load
3 min
Input Current - Maximum
10 A
Battery Recharge Time
12 hr
Output Ports Included
DB9 Serial, EPO, SNMP, USB
Operating Temperature - Minimum
32 Degrees F
Manufacturer Warranty
2 yr, 3 yr Registration
Data Line Protection
Includes Data Line Surge Protection
Number of Outlets - UPS
6
Receptacle Configuration
5-15R
Surge Suppression Rating
567 J
Power Rating - Real
300 W
Number of Outlets - Surge Only
6
Includes Battery
Battery Included
Transfer Time - Maximum
6 msec
Power Rating - Apparent
500 VA
Automatic Voltage Regulation
Includes Automatic Voltage Regulation
Audible Alarm Conditions
Low Battery, Power Outage
External Battery Compatible
Not External Battery Pack Compatible
