- VA Rating - UPS Systems
- 1.5 kVA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 1.5kVA
- Mounting
- Tower
- Wattage
- 900 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V
- Backup Time (Half/Full Load)
- 10 min/2.3 min
- Outlet Type
- (5) Surge; (5) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 10
- Automatic Volts Regulation
- Yes
- Hz
- 50/60 Hz
- Special Features
- Hot Swappable Batteries, Individually Controllable Load Banks
- Fax/Modem Line Protection
- Yes
- Display Type
- LCD
- NEMA Receptacle Configuration
- (10) 5-15R
- Includes
- 1500VA 900W 120V Line-Interactive UPS, USB Cables
- Input Current
- 12 A
- Ports
- USB
- Transfer Time
- 2 msec
- Phase
- Single
- Standards
- CSA (Canada), FCC Part 15 Class B (USA), NOM (Mexico), RoHS, UL1778
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- NEMA Plug Configuration
- 5-15P
- Housing Color
- Black
- Operating Temp. Range
- 122°F (50°C)
- Capacity - Batteries
- 1500 VA/900 W
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- ABS
- Battery Type
- VRLA
- Frequency Compatibility Details
- Automatic frequency selection
- Overvoltage Correction
- Input voltages between 129 and 147 are reduced by 15%
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Cooling Method
- Fan
- Audible Alarm
- Audible alarm indicates power-failure and low-battery conditions
- Rated input current (Maximum Load)
- 12A
- UPS Dataline Suppression
- 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet; Coax jacks (1 set)
- AC Mode Efficiency Rating (100% Load)
- 0.95
- Recommended Electrical Service
- 15A 120V
- Primary Form Factor
- Tower
- Undervoltage Correction
- Input voltages between 92 and 108 are boosted by 18%
- Relative Humidity
- 0 to 95%, non-condensing
- Communications Interface
- USB (HID enabled)
- DC System Voltage (VDC)
- 24
- Front Panel LCD Display
- LCD screen with scroll buttons indicates Input voltage, Output voltage, Frequency (Hz), AVR boost / cut status, Output load in watts, Output load percentage, Battery voltage and Estimated runtime in minutes
- AC Mode BTU / Hr. (Full Load)
- 119
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 92 to 150
- UPS Certifications
- Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A (EMI)
- Communications Cable
- USB and cabling included
- EMI / RFI AC Noise Suppression
- Yes
- Input Phase
- Single-Phase
- Nominal Input Voltage(s) Supported
- 120V AC
- Output kVA Capacity (kVA)
- 1.5
- Network Monitoring Port Description
- Supports detailed monitoring of UPS and site power conditions
- Battery Recharge Rate (Included Batteries)
- Less than 8 hours from 10% to 90%
- Alarm Cancel Operation
- Power-fail alarm can be silenced using alarm-cancel switch
- Output Voltage Regulation (Line Mode)
- 120V (+9% / -12%)
- Half Load Runtime (min.)
- 10 minutes (450 watts)
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- UPS AC Suppression Response Time
- Instantaneous
- UPS AC Suppression Joule Rating
- 650
- Input Circuit Breakers
- 20A
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- High Availability UPS Features
- Hot swappable batteries
- Individually Controllable Load Banks
- No
- Low Voltage Transfer to Battery Power (Setpoint)
- 92
- Internal UPS Replacement Battery Cartridge
- RBC51 (requires 2)
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Battery Mode BTU / Hr. (Full Load)
- 867
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- High Voltage Transfer to Battery Power (Setpoint)
- 150
- Output Watt Capacity (Watts)
- 900
- Switches
- Power switch offers whole UPS power control; Scroll/mute button enables LCD selection options and silences audible alarm; Test button initiates self test
- Output Volt Amp Capacity (VA)
- 1500
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Expandable Runtime
- No
- Output Voltage Regulation (Battery Mode)
- 120V (±10%)
- Load Capacity
- 1500 VA/900 W
- Maximum Operating Temperature
- 122°F (50°C)
- Package Contents
- SMART1500LCDT UPS, USB Cable, Manual with Warranty Information
- USB
- Yes
- Form Factor
- Tower
- Protection Type
- Brownout, Over Voltage
- Typical Battery Recharge Time
- 8 Hour
- Waveform Type
- Pulse-width Modulated Sine Wave
- Surge Energy Rating
- 480 J
- Product Certifications
- CSA (Canada); NOM (Mexico); UL 1778
- Output Capacity (VA)
- 1500
- Installation Form Factors Supported with Included Accessories
- Tower
- Product Compliance
- FCC Part 15 Class A (USA)
- Audible Noise
- Less than 36 dB, front side 1m
- Output Capacity (Watts)
- 900
- Package Includes
- 1500VA 900W 120V Line-Interactive UPS;USB cable;Owner's manual
- UPS Applications
- Home/Office Desktop; Audio/Video; High-End Desktop/Small Network; Retail/Point of Sale; Hospitality
- Frequency
- 50/60 Hz
- Transfer Time - Maximum
- 6 msec
- Run Time - Full Load
- 2.3 min
- Transfer Time - Minimum
- 2 msec
- Power Rating - Apparent
- 1.5 kVA
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Operating Temperature - Minimum
- 32 Degrees F
- Power Rating - Real
- 900 W
- Audible Alarm Conditions
- Low Battery, Power Outage
- Battery Recharge Time
- 8 hr
- Data Line Protection
- Includes Data Line Surge Protection
- Manufacturer Warranty
- 2 yr
- Receptacle Configuration
- 5-15R
- Battery Chemistry
- Valve Regulated Lead Acid
- Number of Outlets - Surge Only
- 8
- Input Current - Maximum
- 12 A
- External Battery Compatible
- Not External Battery Pack Compatible
- Number of Outlets - UPS
- 8
- Output Ports Included
- USB
- Plug Configuration
- 5-15P
- Operating Temperature - Maximum
- 104 Degrees F
- Surge Suppression Rating
- 650 J
- Includes Battery
- Battery Included
- Run Time - Half Load
- 10 min
