- MFR #
- BK500BLK
- Zoro #
- G3367497
- UPC #
- 731304021360
- Country of Origin
- India
- VA Rating - UPS Systems
- 500.0 VA
- Item
- UPS System
- UPS Type
- Standby
- Power Rating
- 500VA
- Mounting
- Floor
- Wattage
- 300 W
- Input Voltage
- 120V AC
- Output Voltage
- 120V AC
- Backup Time (Half/Full Load)
- 13 min 29 sec/3 min 24 sec
- Outlet Type
- (3) Surge; (3) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 6
- Green Environmental Attribute
- Product is Rechargeable
- Ports
- USB
- Hz
- 50/60 Hz (+/-3 Hz)
- Footnotes
- 2,4,6
- Includes
- CD with Software, Cord Management Straps, USB Cables
- Display Type
- LED
- NEMA Receptacle Configuration
- 5-15R
- Input Current
- 12 A
- Standards
- RoHS
- Transfer Time
- 8 to 10 msec
- Fax/Modem Line Protection
- Yes
- Phase
- Single
- NEMA Plug Configuration
- 5-15P
- Special Features
- LED Indicators Provide Proactive Notification of Changing Power and UPS Conditions
- Automatic Volts Regulation
- No
- Housing Color
- Black
- Battery Type
- Sealed Lead Acid (SLA)
- Capacity - Batteries
- 500 VA/300 W
- Voltage
- 120
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- Steel
- Product Certifications
- cUL Listed || California (CEC) Battery Charger || ENERGY STAR V2.0 (USA) || Industry Canada
- Ambient Air Temperature For Operation
- 0-40°C
- Rated Power In Va
- 500 VA
- Input Frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Mounting Location
- front
- Ambient Air Temperature For Storage
- -15-45°C
- Storage Altitude
- 0-50000 ft
- Kw Rating
- 300 W
- Operating Altitude
- 0...10000 ft
- Alarm
- alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- Acoustic Level
- 45 dBA
- Number Of Cables
- 1
- Provided Equipment
- CD with software || Cord management straps || User Manual || USB cable
- Battery Life
- 4-6 year(s)
- Usb Compatible
- Yes
- Relative Humidity
- 0-95 %
- Efficiency At Full Load
- 98...140 V
- Online Thermal Dissipation
- 24 Btu/h
- Control Panel
- LED status display with on line : on battery : replace battery and overload indicators
- Package Contents
- Back-UPS CS 500VA Tower UPS , CD with software, Cord management straps, USB cable, User manual
- Additional Information
- Lifetime data recovery warranty, Serial Connectivity, USB connectivity
- Battery Characteristics
- Spill-proof, Maintenance-free
- Waveform Type
- Stepped Approximated Sine Wave
- Battery Chemistry
- Valve Regulated Lead Acid
- Load Capacity
- 500 VA/300 W
- Typical Battery Recharge Time
- 8 Hour
- Form Factor
- Tower
- Product Series
- CS
- USB
- Yes
- Surge Energy Rating
- 480 J
- Dataline Protection
- RJ-11
- Number of Battery & Surge Outlets
- 6
- Number of Outlets - Surge Only
- 3
- Receptacle Configuration
- 5-15R
- Data Line Protection
- Includes Data Line Surge Protection
- Plug Configuration
- 5-15P
- Battery Life - Minimum
- 4 yr
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Power Rating - Real
- 300 W
- Power Rating - Apparent
- 500 VA
- Transfer Time - Maximum
- 12 msec
- External Battery Compatible
- Not External Battery Pack Compatible
- Output Ports Included
- USB
- Manufacturer Warranty
- 3 yr
- Operating Temperature - Minimum
- 32 Degrees F
- Input Current - Maximum
- 12 A
- Frequency
- 50/60 Hz
- Number of Outlets - UPS
- 6
- Includes Battery
- Battery Included
- Transfer Time - Minimum
- 8 msec
- Replacement Battery Part Number
- RBC2
- Operating Temperature - Maximum
- 104 Degrees F
- Battery Recharge Time
- 8 hr
- Run Time - Full Load
- 3.4 min
- Surge Suppression Rating
- 480 J
- Audible Alarm Conditions
- Low Battery
- Run Time - Half Load
- 13 min
- Green Certification or Other Recognition
- ENERGY STAR(R) Certified
