- VA Rating - UPS Systems
- 1.5 kVA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 1.5kVA
- Mounting
- Rack
- Wattage
- 1.35 kW
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V
- Backup Time (Half/Full Load)
- 13 min/4.5 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- Ports
- DB9 Serial, EPO, USB
- NEMA Receptacle Configuration
- (8) 5-15R
- Hz
- 60 Hz
- Special Features
- Hot Swappable Batteries, Individually Controllable Load Banks
- Standards
- CSA (Canada), FCC Part 15 Class B (USA), NOM (Mexico), RoHS, UL1778
- NEMA Plug Configuration
- 5-15P
- Phase
- Single
- Input Current
- 12 A
- Transfer Time
- 2 to 4 msec
- Display Type
- LCD
- Includes
- (4) Post Rack Mounting Hardware, DB9 Cable, e Cable, EPO Cables, Micro-USB to USB-A Configuration/Console Cable, Pre-Installed Web Card, SMART1500RM2UN SmartPro120V 1.5kVA 1.35kW Line-Interactive Sine Wave UPS, USB-B to USB-A Cable, Xnetwork interface
- Fax/Modem Line Protection
- No
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Automatic Volts Regulation
- Yes
- For Use with
- Server, Telecommunication, Storage Device
- Capacity - Batteries
- 1500 VA/1350 W
- Input Connection
- NEMA 5-15P Plug
- Battery Type
- VRLA
- Housing Material
- Steel
- Half Load Runtime (min.)
- 13 min. (675w)
- EMI / RFI AC Noise Suppression
- Yes
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- Rated input current (Maximum Load)
- 12A
- EPO Port
- RJ11 interface jack with 4 meter cable included. Supports normally open and normally closed EPO systems
- UPS Certifications
- Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
- Audible Noise
- 45 dBA maximum, front side 1m
- Battery Access
- Front panel battery access door
- Individually Controllable Load Banks
- Yes
- Nominal Input Voltage(s) Supported
- 120V AC
- LED Indicators
- Network Link/Activity (Green): Flashes for network activity. Network Speed (Yellow): 10 Mbps (Flashing), 100 Mbps (On steady). LX Platform Interface Status: Normal Operation (Solid Green); Software Update (Alternating Green/Orange ~1/sec); Factory Reset (Alternating Green/Orange ~2/sec).
- UPS AC Suppression Joule Rating
- 570
- Network UPS Tools Compatibility
- NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
- Output kVA Capacity (kVA)
- 1.5
- Battery Replacement Description
- Hot-swappable, user replaceable batteries
- Recommended Electrical Service
- 15A 120V
- Undervoltage Correction
- Input voltages between 83 and 107 are boosted by 14%
- Network Monitoring Port Description
- Includes Pre-installed WEBCARDLX Network Management interface card. RJ45 Network port, Micro-USB Configuration/Console port, USB A port supports a variety of Envirosense2 environmental and control modules. See Accessories>Management Hardware section for more information about these modules.
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Switches
- 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions. LX Platform Interface: Recessed reset switch for interface reboot and factory reset.
- Output kW Capacity (kW)
- 1.35
- Output Watt Capacity (Watts)
- 1350
- High Voltage Transfer to Battery Power (Setpoint)
- 147
- Communications Cable
- Micro-USB, USB, and DB9 cabling included
- Installation Form Factors Supported with Optional Accessories
- 2 post rackmount ( 2POSTRMKITWM ); 2-4 post front rail rackmount ( UPSHDEARKIT ); 4 post rackmount short-depth ( 4POSTRAILKITWM ); Tower ( 2-9USTAND ); Wallmount ( 2POSTRMKITWM )
- DC System Voltage (VDC)
- 36
- Power Factor
- 0.9
- Relative Humidity
- 0 to 95%, non-condensing
- Battery Mode BTU / Hr. (Full Load)
- 1012
- Grounding Lug
- Back panel grounding lug
- Audible Alarm
- Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions
- AC Mode BTU / Hr. (Full Load)
- 267
- Primary Form Factor
- Rackmount
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- UPS AC Suppression Response Time
- Instantaneous
- SNMP Compatibility
- SNMPv1, V2c, V3
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Communications Interface
- DB9 Serial; EPO (emergency power off); Pre-installed network card; USB (HID enabled)
- Input Circuit Breakers
- 15A
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Expandable Runtime
- No
- Network Speed
- 10/100 Mbps
- Internal UPS Replacement Battery Cartridge
- RBC93-2U
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 147
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in Serial or USB communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Output AC Waveform (Battery Mode)
- Pure Sine wave
- Input Phase
- Single-Phase
- Output Voltage Regulation (Line Mode)
- -21%, +8%
- Full Load Runtime (min.)
- 4.5 min. (1350w)
- Front Panel LCD Display
- Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for detailed LCD configuration and monitoring options)
- Overvoltage Correction
- Input voltages between 128 and 147 are reduced by 12%
- Battery Recharge Rate (Included Batteries)
- Less than 4.5 hours from 10% to 90% (typical, full load discharge)
- AC Mode Efficiency Rating (100% Load)
- 0.95
- High Availability UPS Features
- Hot swappable batteries
- Included Mounting Accessory Description
- Included 4POSTRAILKIT mounting bracket enables installation in 4 post racks from 20.5 to 36 inches (521 to 914mm)
- Output Volt Amp Capacity (VA)
- 1500
- Installation Form Factors Supported with Included Accessories
- 4 post 19 inch rackmount
- Low Voltage Transfer to Battery Power (Setpoint)
- 83
- Cooling Method
- Fan
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Alarm Cancel Operation
- Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option available
- Load Management Receptacles
- Two switchable two-outlet 5-15R load banks
- USB
- Yes
- Application/Usage
- Telecommunication, Storage Device, Server
- Network Management
- SNMP Manageable
- Package Contents
- SMART1500RM2UN UPS System with Pre-installed SNMPWEBCARD, Pre-installed WEBCARDLX network interface, USB cable, DB9 cable, EPO cable, Mounting hardware, Owner's manual
- Form Factor
- Rack/Tower
- Software Included
- PowerAlert Software
- Serial Port
- Yes
- Typical Battery Recharge Time
- 4.50 Hour
- TAA Compliant
- Yes
- Load Capacity
- 1500 VA/1350 W
- Emergency Power OFF
- Yes
- Waveform Type
- Pure Sine Wave
- Hot Swappable
- Yes
- Network Management Cards
- WEBCARDLXE
- Package Includes
- SMART1500RM2UN SmartPro 120V 1.5kVA 1.35kW Line-Interactive Sine Wave UPS;Pre-installed WEBCARDLX network interface;USB-B to USB-A cable;Micro-USB to USB-A configuration/console cable;DB9 cable;EPO cable;4-Post rack mounting hardware;Owner's manual
- UPS Applications
- Large Network; High-End Desktop/Small Network
- Output Capacity (VA)
- 1500
- Network Compatibility
- 100 Mbps (Fast Ethernet)
- Grounding Details
- Back panel grounding lug
- Product Certifications
- CSA (Canada); NOM (Mexico); UL 1778
- Output Capacity (Watts)
- 1350
- Product Compliance
- FCC Part 15 Class B (USA)
- Receptacle Configuration
- 5-15R
- Manufacturer Warranty
- 2 yr
- Data Line Protection
- Includes Data Line Surge Protection
- Transfer Time - Maximum
- 4 msec
- Operating Temperature - Minimum
- 32 Degrees F
- Battery Recharge Time
- 4.5 hr
- Number of Outlets - Surge Only
- 8
- Plug Configuration
- 5-15P
- Run Time - Full Load
- 4.5 min
- Includes Battery
- Battery Included
- Output Ports Included
- DB9 Serial, EPO, Pre-Installed Network Card, SNMP, USB
- Battery Chemistry
- Valve Regulated Lead Acid
- Power Rating - Real
- 1.35 kW
- Number of Outlets - UPS
- 8
- Input Current - Maximum
- 12 A
- Audible Alarm Conditions
- Low Battery, Overload, Power Outage, Shutdown, UPS Fault, UPS Startup
- External Battery Compatible
- Not External Battery Pack Compatible
- Operating Temperature - Maximum
- 104 Degrees F
- Power Rating - Apparent
- 1.5 kVA
- Surge Suppression Rating
- 570 J
- Transfer Time - Minimum
- 2 msec
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Frequency
- 60 Hz
