- CAD Available
- Yes
- VA Rating - UPS Systems
- 1.5 kVA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 1.5kVA
- Mounting
- Rack
- Wattage
- 900 W
- Input Voltage
- 230V AC
- Output Voltage
- 220/230/240V AC
- Backup Time (Half/Full Load)
- 12 min/4.5 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- Ports
- Coaxial, DB9, DSL/Ethernet, TEL, USB
- Input Current
- 4.4 A
- NEMA Plug Configuration
- 5-15P
- Display Type
- LCD
- Special Features
- Cold Start Operation Supported
- Phase
- Single
- Includes
- (2) C13 to C14 Cables, (2) Tower/Rackmount Brackets, Coax Cable, USB and Phone (RJ11) Cables
- Automatic Volts Regulation
- Yes
- Hz
- 50/60 Hz
- Transfer Time
- 2 to 4 msec
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Fax/Modem Line Protection
- Yes
- Standards
- CE (Europe), EN 62040-1, EN 62040-2, GOST (Russia), RoHS, SASO (Saudi Arabia)
- NEMA Receptacle Configuration
- (8) C13
- Footnotes
- USB, DB9, and TEL/DSL/ethernet/coax
- Capacity - Batteries
- 1500 VA/900 W
- Battery Type
- Sealed Lead Acid (SLA)
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- ABS
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Cooling Method
- Convection
- EMI / RFI AC Noise Suppression
- Yes
- Battery Replacement Description
- Hot-swappable, user-replaceable internal battery cartridge
- Output Volt Amp Capacity (VA)
- 1500
- UPS Input Connection Description
- Chassis mounted C14 inlet accepts user-supplied AC power cord with country specific cordsets
- Relative Humidity
- 0 to 95%, non-condensing
- Undervoltage Correction
- Input voltages between 177 and 199 are boosted by 14%
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Audible Alarm
- Audible alarm indicates power-failure and low-battery status; Alarm can be disabled entirely via front panel LCD interface (see manual)
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 144 to 282
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- DC System Voltage (VDC)
- 24
- Battery Access
- Includes battery access door
- AC Mode BTU / Hr. (Full Load)
- 133
- High Voltage Transfer to Battery Power (Setpoint)
- 282
- UPS Certifications
- CE; Tested to GOST (Russia); Tested to SASO (Saudi Arabia)
- Expandable Runtime
- No
- Full Load Runtime (min.)
- 4.5 min. (900w)
- Rated input current (Maximum Load)
- 4.4A
- Internal UPS Replacement Battery Cartridge
IMPORTANT BATTERY REPLACEMENT INFORMATION > If your SMX1500LCD UPS has no battery replacement door, please contact a local electronics repair technician to source and install a matching replacement battery; If your SMX1500LCD UPS is equipped with a battery access door, please order Tripp Lite RBC1500 (quantity 1) replacement battery
- Output Watt Capacity (Watts)
- 900
- UPS Certification Details
- CE Class A (EMI); CE IEC 62040-1-1, 62040-1-2
- Severe Undervoltage Correction
- Input voltages between 144 and 176 are boosted by 30%
- Low Voltage Transfer to Battery Power (Setpoint)
- 144
- Nominal Input Voltage(s) Supported
- 230V AC
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- UPS AC Suppression Response Time
- Instantaneous
- Output AC Waveform (Battery Mode)
- PWM sine wave
- LED Indicators
- Front panel LCD display
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- Communications Cable
- USB cabling included
- Network Monitoring Port Description
- Supports detailed monitoring of UPS and site power conditions
- Primary Form Factor
- Rackmount
- UPS Dataline Suppression Details
- RJ11 telephone cable included
- Input Circuit Breakers
- 5A
- UPS AC Suppression Joule Rating
- 360
- Battery Recharge Rate (Included Batteries)
- 4.5 hours from 10% to 90%
- UPS Dataline Suppression
- 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
- Output kVA Capacity (kVA)
- 1.5
- Nominal Output Voltage(s) Supported
- 220V; 230V; 240V
- AC Mode Efficiency Rating (100% Load)
- 0.96
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Half Load Runtime (min.)
- 12 min. (450w)
- Output Voltage Regulation (Line Mode)
- -18%, +8%
- Switches
- ON/OFF/MODE button provides UPS on/off power control (long-press) and advances the LCD screen display (short tap); MUTE/ENTER button provides temporary alarm cancel, plus selection and confirmation of on-screen configuration options
- Battery Mode BTU / Hr. (Full Load)
- 542
- Included Mounting Accessory Description
- Included mounting brackets enable installation in 2 and 4 post racks, plus upright tower configurations; Set of 4 rubber-feet enable no-slip horizontal desktop placement
- Individually Controllable Load Banks
- No
- Included Output Power Cables
- Includes 2 C13 to C14 output power cables.
- Communications Interface
- USB (HID enabled); DB9 Serial
- Installation Form Factors Supported with Included Accessories
- 2 post 19 inch rackmount; 4 post 19 inch rackmount; Tower
- Input Phase
- Single-Phase
- Frequency Compatibility Details
- Automatic frequency selection
- Hot-Swap PDU options
- PDUBHV10 (2U / 8 C13 outlets)
- Alarm Cancel Operation
- Press the MUTE/ENTER button during a power failure to silence the alarm; Once silenced, alarm will re-sound to indicate low-battery status
- Overvoltage Correction
- Input voltages between 245 and 282 are reduced by 12%
- Front Panel LCD Display
Backlighted LCD screen offers detailed UPS status information, configuration options and Error message reporting; STATUS INFORMATION includes Input Voltage, Output Voltage, Estimated Runtime (minutes), Output Load Percentage, Output Load Wattage, Battery Charge Percentage, Graphical 5-Bar Battery Charge Level and UPS Operating Mode Display; CONFIGURATION OPTIONS include Power Sensitivity, LCD Status Information Scrolling, Alarm Disable, LCD Brightness and Self Test / REPORTED ERROR MESSAGES include Replace-Battery and Overload conditions; LCD Screen rotates for vertical or horizontal UPS placement
- Dataline Protection
- RJ-11
- Typical Battery Recharge Time
- 8 Hour
- Load Capacity
- 1500 VA/900 W
- Additional Information
- Appearance: Attractive black color schemeOutput voltage regulation: Battery Mode: PWM sine wave 230V +/-5%Output frequency regulation: Line Mode: Passes line frequency of 50/60Hz +/-10%, Battery Mode: Inverter output regulated to 50/60Hz +/-0.5Hz
- Package Contents
- SmartPro SMX1500LCD 1500VA Tower/Rack Mountable Digital UPS, SMX1500LCD Digital UPS System, USB cable, phone (RJ11) cable and coax cable, 2 C13-to-C14 jumper cables, 2 tower/rackmount brackets, Owner's manual with warranty information
- Form Factor
- Rack-mountable, Tower
- Software Included
- PowerAlert Software
- Serial Port
- Yes
- Battery Chemistry
- Valve Regulated Lead Acid
- USB
- Yes
- Product Certifications
- GOST (Russia); EN 62040-1; EN 62040-2
- Output Capacity (VA)
- 1500
- Product Compliance
- SASO (Saudi Arabia); CE (Europe)
- Output Capacity (Watts)
- 900
- High Availability UPS Features
- Automatic Voltage Regulation (AVR); Hot swappable batteries; Surge/noise protection
- UPS Applications
- Home/Office Desktop; Audio/Video
- Package Includes
- SMX1500LCD 1500VA 900W 230V Line-Interactive UPS with 8 Outlets;USB cable;RJ11 cable;(2) C13 to C14 power cables;Tower/rack mounting hardware;Owner's manual
- Input Frequency
- ±3Hz
- Transfer Time - Maximum
- 3 msec
- Operating Temperature - Minimum
- 32 Degrees F
- Frequency
- 50/60 Hz
- Audible Alarm Conditions
- Low Battery, Power Outage
- Number of Outlets - UPS
- 8
- Includes Battery
- Battery Included
- Power Rating - Real
- 900 W
- Plug Configuration
- C14
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Data Line Protection
- Includes Data Line Surge Protection
- Surge Suppression Rating
- 360 J
- Manufacturer Warranty
- 2 yr, 3 yr Registration
- Transfer Time - Minimum
- 2 msec
- Number of Outlets - Surge Only
- 8
- Battery Recharge Time
- 4.5 hr
- External Battery Compatible
- Not External Battery Pack Compatible
- Input Current - Maximum
- 4.4 A
- Power Rating - Apparent
- 1.5 kVA
- Run Time - Full Load
- 4.5 min
- Receptacle Configuration
- C13
- Operating Temperature - Maximum
- 104 Degrees F
- Output Ports Included
- Coaxial, DB9 Serial, DSL/Ethernet, USB
