- VA Rating - UPS Systems
- 2.2 kVA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 1.95kVA
- Mounting
- Desktop/Tower
- Wattage
- 1.95 kW
- Input Voltage
- 120V AC
- Output Voltage
- 100/110/120/125V AC
- Backup Time (Half/Full Load)
- 12 min/4 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 4
- Input Current
- 16 A
- Phase
- Single
- Footnotes
- 4,8
- Transfer Time
- 5 msec
- Automatic Volts Regulation
- Yes
- Display Type
- LCD
- Includes
- (4) Post Rack Mount Installation Kits, PowerAlert Software with USB, Serial and EPO Cables
- NEMA Plug Configuration
- 5-15P
- Special Features
- Cold Start Operation Supported, Hot Swappable Batteries
- NEMA Receptacle Configuration
- (4) 5-15R; (4) 5-15/20R
- Fax/Modem Line Protection
- No
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Standards
- CSA (Canada), ENERGY STAR Qualified, FCC Part 15 Class a (USA), RoHS, UL1778
- Ports
- EPO, RS232, USB
- Hz
- 60 Hz
- Capacity - Batteries
- 2200 VA/1920 W
- Operating Temp. Range
- 104°F (40°C)
- Input Connection
- NEMA 5-15P Plug
- Battery Type
- VRLA
- Housing Material
- Polycarbonate
- Input Circuit Breakers
- 20A
- Battery Recharge Rate (Included Batteries)
- Less than 4.5 hours from 10% to 90% (typical, full load discharge)
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Communications Cable
- USB, DB9 and EPO cabling included
- Output AC Waveform (Battery Mode)
- Pure Sine wave
- Battery Replacement Description
- Hot-swappable, user replaceable batteries
- Rated input current (Maximum Load)
- 16A (120V)
- Primary Form Factor
- Rackmount
- High Voltage Transfer to Battery Power (Setpoint)
- 145
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Power Factor
- 0.87
- Installation Form Factors Supported with Included Accessories
- 4 post 19 inch rackmount
- Half Load Runtime (min.)
- 12 min. (960w)
- Battery Mode BTU / Hr. (Full Load)
- 1157
- Audible Noise
- 45 dBA maximum, front side 1m
- AC Mode Efficiency Rating (100% Load)
- 0.96
- Network UPS Tools Compatibility
- NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
- Network Monitoring Port Description
- Supports detailed monitoring of UPS and site power conditions
- Network Management Cards
- SNMPWEBCARD ; TLNETCARD ; WEBCARDLX ; RELAYIOCARD
- Individually Controllable Load Banks
- Yes
- Output kW Capacity (kW)
- 1.92
- Switches
- 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions
- Input Phase
- Single-Phase
- UPS Certification Details
- SAFETY STANDARD (U.S.) - UL1778:2014 (5th Ed) R10.17; SAFETY STANDARD (CANADA) - CAN/CSA-C22.2 No. 107.3-14 (3rd Ed) + GI1 / FCC/ICES COMPLIANT - CLASS A
- Overvoltage Correction
- Input voltages between 127 and 145 are reduced by 12%
- Grounding Lug
- Back panel grounding lug
- Recommended Electrical Service
- 20A 120V
- Included Mounting Accessory Description
- Included 4POSTRAILKIT mounting bracket enables installation in 4 post racks from 20.5 to 36 inches (521 to 914mm)
- Full Load Runtime (min.)
- 4.5 min. (1920w)
- Output Watt Capacity (Watts)
- 1920
- AC Mode BTU / Hr. (Full Load)
- 306
- Audible Alarm
- Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions
- Battery Access
- Front panel battery access door
- Alarm Cancel Operation
- Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option available
- DC System Voltage (VDC)
- 48
- Severe Undervoltage Correction
- Input voltages between 83 and 95 are boosted by 24%
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 145
- High Availability UPS Features
- Hot swappable batteries
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- EMI / RFI AC Noise Suppression
- Yes
- Output Voltage Regulation (Line Mode)
- -14%, +6%
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- UPS AC Suppression Joule Rating
- 570
- Undervoltage Correction
- Input voltages between 108 and 96 are boosted by 12%
- Installation Form Factors Supported with Optional Accessories
- 2 post rackmount ( 2POSTRMKITWM ); 2-4 post front rail rackmount ( UPSHDEARKIT ); 4 post rackmount short-depth ( 4POSTRAILKITWM ); Tower ( 2-9USTAND ); Wallmount ( 2POSTRMKITWM )
- Expandable Runtime
- No
- Low Voltage Transfer to Battery Power (Setpoint)
- 83
- Output Volt Amp Capacity (VA)
- 2200
- Output kVA Capacity (kVA)
- 2.2
- UPS AC Suppression Response Time
- Instantaneous
- Internal UPS Replacement Battery Cartridge
- RBC94-2U
- Communications Interface
- USB (HID enabled); DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface
- Load Management Receptacles
- Two switchable single-outlet load banks
- Front Panel LCD Display
- Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual for detailed LCD configuration and monitoring options)
- UPS Certifications
- Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
- Nominal Input Voltage(s) Supported
- 120V AC
- Cooling Method
- Fan
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Relative Humidity
- 0 to 95%, non-condensing
- Load Capacity
- 2200 VA/1920 W
- Protection Type
- Under Voltage, Over Voltage
- Alarm
- Low Battery, On Battery, Overload
- Maximum Operating Temperature
- 104°F (40°C)
- Software Included
- PowerAlert Software
- Emergency Power OFF
- Yes
- Network Management
- SNMP Manageable
- USB
- Yes
- Waveform Type
- Sine Wave
- Serial Port
- Yes
- Status Indicators
- 5 Front Panel Leds: Green Power Led, Green Voltage Correction Led, 3 Color Battery Charge Led, 3 Color Output Load Led, Red Battery Warning Led
- TAA Compliant
- Yes
- Hot Swappable
- Yes
- Typical Battery Recharge Time
- 4.50 Hour
- Form Factor
- Rack-mountable
- Package Contents
- SMART2200RM2U UPS System, PowerAlert Software CD, USB Cable, Serial Cable, EPO Cable, Owner's Manual with Warranty Information
- Output Capacity (Watts)
- 1950
- LED Indicators
- 3 status-indicating LEDs (normal, battery mode, alarm); LED light bar (blue = nominal, blinking blue = warning, red = alarm)
- Output Capacity (VA)
- 1950
- Emergency Power Off (EPO)/Remote On-Off (ROO)
- Yes
- UPS Applications
- High-End Desktop/Small Network; Large Network
- Grounding Details
- Rear panel grounding lug
- Operating Elevation (ft.)
- 0-10,000
- Package Includes
- 1950VA 1950W 120V Line-Interactive UPS;USB cable;DB9 cable;Rack-mounting hardware;Tower support stands;Safety instructions
- Product Compliance
- ENERGY STAR Qualified; FCC Part 15 Class A (USA)
- Nominal Input Voltage Description
- 80V-151V; adjustable to 70-153V
- Product Certifications
- CSA (Canada); UL 1778
- Storage Elevation (ft.)
- 0-32,808
- Transfer Time - Minimum
- 1 msec
- Power Rating - Real
- 1.92 kW
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Manufacturer Warranty
- 2 yr, 3 yr Registration
- Input Current - Maximum
- 16 A
- Run Time - Full Load
- 4 min
- Includes Battery
- Battery Included
- Output Ports Included
- EPO, RS-232, USB
- Battery Recharge Time
- 4.5 hr
- Surge Suppression Rating
- 380 J
- Operating Temperature - Minimum
- 32 Degrees F
- Audible Alarm Conditions
- Low Battery, Overload, Power Outage
- Battery Chemistry
- Valve Regulated Lead Acid
- Frequency
- 60 Hz
- Plug Configuration
- 5-20P
- Receptacle Configuration
- 5-15R
- Operating Temperature - Maximum
- 104 Degrees F
- Number of Outlets - Surge Only
- 7
- Number of Outlets - UPS
- 7
- Data Line Protection
- Includes Data Line Surge Protection
- Transfer Time - Maximum
- 4 msec
- External Battery Compatible
- Not External Battery Pack Compatible
- Power Rating - Apparent
- 2.2 kVA
- Run Time - Half Load
- 12 min
