VA Rating - UPS Systems
550.0 VA
Output Voltage
110/115/120V AC
Backup Time (Half/Full Load)
5 min/1.2 min
Outlet Type
(4) Surge; (4) UPS/Surge
Transfer Time
2 msec from Battery to AC, 4 msec from AC to Battery
NEMA Plug Configuration
5-15P
NEMA Receptacle Configuration
(10) 5-15R
Special Features
Mountable Housing, Widely Spaced Outlets Accommodate Large Transformer Plugs, Poweralert Software, Keyhole Mounting Flanges
Standards
CSA-C22.2 No. 107.3, FCC Part 15 Class B, FCC Part 68, NOM, RoHS, UL1778
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Automatic Volts Regulation
No
Fax/Modem Line Protection
Yes
For Use with
Audio System, Home/Office, Router, Blu-ray Player, Storage Device, Commercial, Media Player, TV, Media Center, Computer, DVR, Gaming Console, Printer
Capacity - Batteries
550 VA/300 W
Input Connection
6 ft Cord with NEMA 5-15P Plug
High Voltage Transfer to Battery Power (Setpoint)
145
Output AC Waveform (Battery Mode)
PWM sine wave
WatchDog Compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
AC Mode BTU / Hr. (Full Load)
13.1
Nominal Input Voltage(s) Supported
120V AC
Nominal Output Voltage(s) Supported
110V; 115V; 120V
Battery Access
Battery access door
Installation Form Factors Supported with Included Accessories
Tower; Ultra-compact desktop; Wallmount
Cold Start (Startup in Battery Mode During a Power Failure)
Cold-start operation supported
UPS Dataline Suppression
1 line TEL/DSL or Ethernet
Primary Form Factor
Desktop
Communications Cable
USB interface cable included
Output Voltage Regulation (Line Mode)
120V (±20%)
Rated input current (Maximum Load)
6A
Storage Temperature Range
+5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
Output Voltage Regulation (Battery Mode)
120V (±10%)
Input Circuit Breakers
7A
Output Volt Amp Capacity (VA)
550
Individually Controllable Load Banks
No
AC Mode Efficiency Rating (100% Load)
>98%
Switches
Switch controls power off/on status
UPS Certifications
Meets FCC Part 15 Category B (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
Output Watt Capacity (Watts)
300
Relative Humidity
0 to 90%, non-condensing
PowerAlert Software
For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
Operating Elevation (m)
Up to 3000m
EMI / RFI AC Noise Suppression
Yes
Audible Alarm
UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
Half Load Runtime (min.)
5 min. (150w)
UPS AC Suppression Response Time
Instantaneous
Full Load Runtime (min.)
1.2 min. (300w)
LED Indicators
1 Status LED reports operating mode and fault status
Operating Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Battery Replacement Description
Replaceable internal batteries (see manual)
Battery Recharge Rate (Included Batteries)
6.5 hours (10% to 90%)
UPS AC Suppression Joule Rating
316
DC System Voltage (VDC)
12
Low Voltage Transfer to Battery Power (Setpoint)
95
Operating Elevation (ft.)
Up to 10,000 ft.
UPS Certification Details
UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS B; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia)
High Availability UPS Features
Battery Independent Restart
Communications Interface
USB (HID enabled)
Recommended Electrical Service
15A 120V
Software Included
PowerAlert Software
Protection Type
Black Out, Surge, Over Voltage, Brownout, Line Noise
Status Indicators
1 x Status LED reports operating mode and fault status
Number of Battery & Surge Outlets
5
Storage Temperature
5°F (-15°C) - 113°F (45°C)
Waveform Type
Pure Sine Wave
Dataline Protection
RJ-11, RJ-45
Form Factor
Ultra-compact Desktop/Tower/Wall Mount
Package Contents
Internet Office INTERNET550U 550VA UPS, USB cable, Owner's Manual
Maximum Operating Elevation
10000 ft
Load Capacity
550 VA/300 W
Application/Usage
Printer, Gaming Console, Computer, Commercial, Blu-ray Player, TV, Router, Home/Office, Media Center, Audio System, Media Player, DVR, Storage Device
Typical Battery Recharge Time
6.50 Hour
Energy Saving
Greater than 95% efficiency - GREEN UPS
Alarm
Fault, Replace Battery, Overload, Low Battery
USB (HID Compliant) Port
Yes
Surge Energy Rating
316 J
UPS Applications
Computer/Peripherals; Retail/Point of Sale; Hospitality
Package Includes
INTERNET550U 550VA 300W 120V Standby UPS with 10 Outlets;USB cable;Owner's manual
Output Capacity (Watts)
300
Product Compliance
FCC Part 15 Class B (USA); FCC Part 68
Product Certifications
CAN/CSA-C22.2 No. 107.3 (Canada); NOM (Mexico); RETIE (Colombia); UL 1778
Internal UPS Replacement Battery Cartridge
IMPORTANT BATTERY REPLACEMENT INFORMATION > If your INTERNET550U has no battery access door, please contact a local electronics repair technician to source and install a matching replacement battery; If your INTERNET550U UPS does have a battery replacement door and the original battery inside has a rating of 12V 3.6AH, please order Tripp Lite replacement battery Model Number RBC36H
Includes Battery
Battery Included
Visible Indicator Light Conditions
Fault
Power Rating - Apparent
550 VA
Number of Outlets - Surge Only
5
Input Current - Maximum
6 A
Automatic Voltage Regulation
No Automatic Voltage Regulation
Output Ports Included
USB
Battery Recharge Time
6.5 hr
Data Line Protection
Includes Data Line Surge Protection
Run Time - Full Load
1.2 min
Operating Temperature - Minimum
32 Degrees F
Transfer Time - Maximum
10 msec
Replacement Battery Part Number
RBC36H
Operating Temperature - Maximum
104 Degrees F
Battery Chemistry
Valve Regulated Lead Acid
Number of Outlets - UPS
5
Power Rating - Real
300 W
Manufacturer Warranty
3 yr Limited
Surge Suppression Rating
316 J
Transfer Time - Minimum
6 msec
Audible Alarm Conditions
Low Battery, Overload, Replace Battery
Receptacle Configuration
5-15R
External Battery Compatible
Not External Battery Pack Compatible
