- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 650VA
- Mounting
- Tower
- Wattage
- 350 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 12 min/3.2 min
- Outlet Type
- (4) Surge; (4) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 8
- Input Current
- 12 A
- NEMA Receptacle Configuration
- (8) 5-15R
- Automatic Volts Regulation
- Yes
- Transfer Time
- 4 msec
- Footnotes
- 4
- VA Rating - UPS Systems
- 650.0 VA
- Includes
- UPS System
- Phase
- Single
- Ports
- USB (HID enabled)
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Display Type
- LCD
- Hz
- 60 Hz
- Fax/Modem Line Protection
- No
- Special Features
- USB Port And Poweralert Software Enables Unattended Shutdown In Case Of Extended Power Failure
- NEMA Plug Configuration
- 5-15P
- Standards
- CSA, FCC Part 15 Class B, NOM, RoHS, UL1778
- Voltage
- 120
- Operating Temp. Range
- 122°F (50°C)
- Capacity - Batteries
- 650 VA/350 W
- Housing Color
- Black
- Input Connection
- 6 ft Cord with NEMA 5-15P Plug
- Housing Material
- ABS
- Battery Type
- VRLA
- Input Phase
- Single-Phase
- Communications Interface
- USB (HID enabled)
- High Voltage Transfer to Battery Power (Setpoint)
- 139
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in communication ports , download PowerAlert Local software at http://www.tripplite.com/poweralert
- Battery Recharge Rate (Included Batteries)
- Less than 20 hours from 10 to 90%
- UPS Certifications
- Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
- Expandable Runtime
- No
- Communications Cable
- User supplies USB cable
- Low Voltage Transfer to Battery Power (Setpoint)
- 89
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Output Volt Amp Capacity (VA)
- 650
- Cooling Method
- Convection
- Front Panel LCD Display
- Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace battery status; LCD screen rotates for rack/tower viewing
- Internal UPS Replacement Battery Cartridge
- RBC51
- Undervoltage Correction
- Input voltages between 89 and 104 are boosted by 14%
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Relative Humidity
- 0 to 95%, non-condensing
- AC Mode BTU / Hr. (Full Load)
- 31
- Output Watt Capacity (Watts)
- 350
- Primary Form Factor
- Tower
- UPS AC Suppression Response Time
- Instantaneous
- Battery Mode BTU / Hr. (Full Load)
- 442
- DC System Voltage (VDC)
- 12
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Individually Controllable Load Banks
- No
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Alarm Cancel Operation
- Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
- Hot-Swap PDU options
- PDUB15 (2U / 8 5-15R outlets)
- Full Load Runtime (min.)
- 3.2 min. (350w)
- Battery Replacement Description
- Hot-swappable, user replaceable batteries
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
- Battery Access
- Battery access door
- Nominal Input Voltage(s) Supported
- 120V AC
- Rated input current (Maximum Load)
- 12A
- Installation Form Factors Supported with Included Accessories
- Tower
- UPS AC Suppression Joule Rating
- 480
- Half Load Runtime (min.)
- 12 min. (175w)
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- Switches
- 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness
- Audible Alarm
- Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software
- Network UPS Tools Compatibility
- NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- LED Indicators
- Front panel LCD display
- Recommended Electrical Service
- 15A 120V
- AC Mode Efficiency Rating (100% Load)
- 0.97
- Typical Battery Recharge Time
- 8 Hour
- USB
- Yes
- Maximum Operating Temperature
- 122°F (50°C)
- Alarm
- Self-test Operation
- Protection Type
- Brownout
- Waveform Type
- Pulse-width Modulated Sine Wave
- Load Capacity
- 650 VA/350 W
- Status Indicators
Input Voltage : Shows actual incoming voltage in real time, Battery Charge : Shows approximate charge available on the battery, Automatic Voltage Regulation (AVR) : Illuminates to indicate the UPS is automatically regulating incoming voltage without draining battery power, Battery Recharge/Replace : Illuminates to indicate the UPS batteries need to be recharged or replaced (following a self-test), Battery Backup : Illuminates to indicate that the UPS is supplying battery power to connected equipment, Output Load Level : Illuminates when the electrical load of connected equipment exceeds the capacity of the UPS
- Surge Energy Rating
- 480 J
- Package Contents
- OmniSmart 650 VA Digital UPS, OMNI650LCD Digital UPS System, Manual with warranty information
- Assembly Required
- No
- UPS Applications
- Home/Office Desktop; Audio/Video; Retail/Point of Sale; Hospitality
- Output Capacity (VA)
- 650
- High Availability UPS Features
- Automatic Voltage Regulation (AVR); Hot swappable batteries; Surge/noise protection
- Package Includes
- OMNI650LCD UPS System;Instruction manual
- Product Compliance
- FCC Part 15 Class B (USA)
- Product Certifications
- CSA (Canada); NOM (Mexico); UL 1778
- Output Capacity (Watts)
- 350
- Replacement Battery Part Number
- RBC51
- Power Rating - Real
- 350 W
- Power Rating - Apparent
- 650 VA
- Run Time - Full Load
- 3.2 min
- Transfer Time - Maximum
- 4 msec
- Manufacturer Warranty
- 3 yr Limited
- Operating Temperature - Maximum
- 104 Degrees F
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Data Line Protection
- No Data Line Surge Protection
- Audible Alarm Conditions
- Low Battery, Power Outage
- Output Ports Included
- USB
- Operating Temperature - Minimum
- 32 Degrees F
- External Battery Compatible
- Not External Battery Pack Compatible
- Frequency
- 60 Hz
- Includes Battery
- Battery Included
- Plug Configuration
- 5-15P
- Number of Outlets - UPS
- 4
- Visible Indicator Light Conditions
- Overload, Replace Battery
- Receptacle Configuration
- 5-15R
- Input Current - Maximum
- 12 A
- Battery Recharge Time
- 20 hr
- Battery Chemistry
- Valve Regulated Lead Acid
- Number of Outlets - Surge Only
- 4
