- Item
- UPS System
- VA Rating - UPS Systems
- 750.0 VA
- UPS Type
- Standby
- Power Rating
- 750VA
- Mounting
- Desktop/Tower
- Wattage
- 450 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 8.6 min/2 min
- Outlet Type
- (6) Surge; (6) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 12
- Footnotes
- 4,6
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Includes
- USB Cables
- NEMA Plug Configuration
- 5-15P
- Special Features
- Cold Start Operation Supported
- Ports
- TEL/DSL, USB
- Phase
- Single
- NEMA Receptacle Configuration
- (12) 5-15R
- Hz
- 60 Hz
- Fax/Modem Line Protection
- Yes
- Automatic Volts Regulation
- No
- Transfer Time
- 2 to 4 msec
- Input Current
- 10 A
- Standards
- CSA, FCC Part 15 Class B, NOM, RoHS, UL1778
- Display Type
- No Display
- Operating Temp. Range
- 104°F (40°C)
- For Use with
- Audio System, Home Theater, Gaming Console, Blu-ray Player, DVR, Digital Signage, Media Center, TV, Router, Desktop Computer, Home/Office, Media Player, Commercial, Server, Printer
- Housing Color
- Black
- Battery Type
- Sealed Lead Acid (SLA)
- Capacity - Batteries
- 750 VA/450 W
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- ABS
- LED Indicators
- Set of 3 status LEDs indicate operating mode, low-battery, overload, replace-battery and fault conditions
- Operating Elevation (m)
- Up to 3000m
- Input Phase
- Single-Phase
- Output Volt Amp Capacity (VA)
- 750
- Half Load Runtime (min.)
- 8.6 min. (225w)
- Nominal Input Voltage(s) Supported
- 120V AC
- Input Circuit Breakers
- 10A
- Storage Temperature Range
- +5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius
- Installation Form Factors Supported with Included Accessories
- Tower; Ultra-compact desktop; Wallmount
- Operating Elevation (ft.)
- Up to 10,000 ft.
- Output Voltage Regulation (Battery Mode)
- 120V (±10%)
- Internal UPS Replacement Battery Cartridge
- RBC51
- Output Voltage Regulation (Line Mode)
- 120V (±20%)
- Battery Replacement Description
- Replaceable internal batteries (see manual)
- UPS AC Suppression Joule Rating
- 316
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- Output Watt Capacity (Watts)
- 450
- Primary Form Factor
- Desktop
- UPS Dataline Suppression
- 1 line TEL/DSL or Ethernet
- Audible Alarm
- UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions
- AC Mode Efficiency Rating (100% Load)
- >98%
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Full Load Runtime (min.)
- 2 min. (450w)
- Communications Cable
- USB interface cable included
- AC Mode BTU / Hr. (Full Load)
- 8.3
- UPS AC Suppression Response Time
- Instantaneous
- High Voltage Transfer to Battery Power (Setpoint)
- 145
- Individually Controllable Load Banks
- No
- Recommended Electrical Service
- 15A 120V
- DC System Voltage (VDC)
- 12
- Relative Humidity
- 0 to 90%, non-condensing
- Expandable Runtime
- No
- Switches
- Switch controls power off/on status
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- UPS Certification Details
- UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS B; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia)
- Battery Access
- Battery access door
- Low Voltage Transfer to Battery Power (Setpoint)
- 95
- Rated input current (Maximum Load)
- 10A
- EMI / RFI AC Noise Suppression
- Yes
- High Availability UPS Features
- Battery Independent Restart
- Communications Interface
- USB (HID enabled)
- Output AC Waveform (Battery Mode)
- PWM sine wave
- Hot-Swap PDU options
- PDUB15 (2U / 8 5-15R outlets)
- UPS Certifications
- ENERGY STAR Qualified; Meets FCC Part 15 Category B (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)
- Battery Recharge Rate (Included Batteries)
- 8 hours (10% to 90%)
- Load Capacity
- 750 VA/450 W
- Dataline Protection
- RJ-11
- Battery Life
- 6 Year
- Application/Usage
- Commercial, Media Player, Server, Blu-ray Player, Digital Signage, Desktop Computer, Router, DVR, TV, Media Center, Audio System, Gaming Console, Home/Office, Home Theater, Printer
- Package Contents
- Internet Office 750VA UPS, USB cable and phone cord, Instruction manual with warranty information
- Alarm
- Self-test Operation, On Battery
- Battery Chemistry
- Valve Regulated Lead Acid
- Status Indicators
- 2 LEDs indicate on/off and overload/check battery
- Protection Type
- Brownout, Black Out, Surge, Over Voltage, Line Noise
- Surge Energy Rating
- 380 J
- USB
- Yes
- Number of Battery & Surge Outlets
- 6
- Modem (RJ-11)
- Yes
- Additional Information
INTERNET750U standby UPS offers complete protection from blackouts, brownouts and surges on AC and tel/DSL dataline connections, 12 widely spaced outlets accommodate large transformer plugs without blocking outlets, 6 battery-supported outlets protect computers and vital system peripherals. 6 surge suppression-only outlets protect system accessories that do not require battery support, Provides battery-derived AC output during blackouts and brownouts, 750VA/450W power handling ability supports a variety of PCs, workstations and other sensitive electronics, Supports entry-level PC systems up to 35 min. during blackouts, Single-line tel/DSL surge suppression with line splitter protects two directly connected modems, fax machines or cordless phones sharing a single phone line connection, USB port, FREE PowerAlert Software and cabling provide monitoring of site power conditions, HID-compliant USB interface enables full integration with built-in power management and auto shutdown features of Windows, Mac OS X and Linux, Supports Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application/OS or hard power off/on reboot of connected equipment; ideal for unattended kiosk applications, Hot-swap battery replacement supported via battery access door, Space-saving ultra-compact housing, Keyhole mounting flanges enable secure wallmount installation, $100,000 Ultimate Lifetime Insurance protects connected equipment from surge damage (USA & Canada only)
- Form Factor
- Ultra-compact Desk-mount
- Maximum Operating Temperature
- 104°F (40°C)
- Waveform Type
- Pulse-width Modulated Sine Wave
- Hot Swappable
- Yes
- Typical Battery Recharge Time
- 4 Hour
- Software Included
- PowerAlert Software
- Assembly Required
- No
- Voltage Regulation Description
- Input voltage range of 95 to 145
- Product Certifications
- RETIE (Colombia); CSA (Canada); NOM (Mexico); UL 1778
- UPS Applications
- Computer/Peripherals; Audio/Video; Retail/Point of Sale; Hospitality
- Power Factor
- 0.6
- Package Includes
- INTERNET750U 750VA 450W 120V Standby UPS with 12 Outlets;USB cable;Owner's manual
- Product Compliance
- ENERGY STAR Qualified; FCC Part 15 Class B (USA)
- Output Capacity Details
- 6.3A @ 120V. 110%±10%,GOES TO FAULT AFTER 5MIN; 120%±10%,GOES TO FAULT IMMEDIATELY 110%±10%,SHUTS DOWN IN 5 SEC; 120%±10%, SHUTS DOWN IMMEDIATELY
- Frequency Compatibility Details
- Output is regulated to +/-0.05Hz when input frequency exceeds +/-5Hz of nominal.
- Output Capacity (Watts)
- 450
- Output Capacity (VA)
- 750
- Plug Configuration
- 5-15P
- Manufacturer Warranty
- 3 yr Limited
- Transfer Time - Maximum
- 10 msec
- Replacement Battery Part Number
- RBC51
- Number of Outlets - Surge Only
- 6
- Power Rating - Real
- 450 W
- External Battery Compatible
- Not External Battery Pack Compatible
- Number of Outlets - UPS
- 6
- Includes Battery
- Battery Included
- Output Ports Included
- USB
- Receptacle Configuration
- 5-15R
- Input Current - Maximum
- 10 A
- Operating Temperature - Maximum
- 104 Degrees F
- Operating Temperature - Minimum
- 32 Degrees F
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Battery Recharge Time
- 8 hr
- Visible Indicator Light Conditions
- Battery Low, Fault, Overload, Replace Battery
- Frequency
- 50/60 Hz
- Audible Alarm Conditions
- Low Battery, Overload, Replace Battery
- Power Rating - Apparent
- 750 VA
- Transfer Time - Minimum
- 6 msec
- Run Time - Full Load
- 2 min
- Data Line Protection
- Includes Data Line Surge Protection
- Surge Suppression Rating
- 316 J
- Run Time - Half Load
- 8.6 min
