  9. Analog Panel Meter, AC, 68mm x 68mm, Screw
Trumeter Analog Panel Meter, AC, 68mm x 68mm, Screw APM-M2-APO - main

Analog Panel Meter, AC, 68mm x 68mm, Screw

  • Mfr # APM-M2-APO

  • Zoro # G806116094

product price: $153.99
/ea
Free Shipping & Returns

Key Features

Standards
CE, CUL, RoHS, UL, UL50
Accuracy
1%
Includes
Mounting Brackets, Screws
Size (In.)
2.83 x 2.83 x 2.09 in
Type
AC Current; AC Voltage; DC Current; DC Voltage; Frequency
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
APM-M2-APO
Zoro #
G806116094
UPC #
-
Country of Origin
Malaysia

Dimensions

Size (In.)
2.83 x 2.83 x 2.09 in
Manufacturers Warranty Length
3 yr
Overall Width
2.83 in
Overall Height
2.83 in
Cutout Width
2 5/8 in
Cutout Height
2 11/16 in
Overall Depth
2.09 in
Digit Height - Minimum
0.23 in
Digit Height - Maximum
0.47 in

Details

Item
Meter
Standards
CE, CUL, RoHS, UL, UL50
Accuracy
1%
Includes
Mounting Brackets, Screws
Type
AC Current; AC Voltage; DC Current; DC Voltage; Frequency
Range
0 to 600 V DC/AC; 0 to 10,000 A (Continuous); 2 to 400 Hz; 0 to 5 A (Direct)
Display Digits
4
Connector Type
Screw Terminal
Output
4-20mA
Use With
Switchgear and Power Control Center
Display
Posistive Digit LCD
Interface
RS-485
Input Range
0 to 10,000 A (via CT), 0 to 5 A (Direct)
Display Span
9999
Mounting
Screws
Fits
68mm x 68mm
NEMA Rating
4; 12
Parameters Measured
AC Voltage
Includes Mounting Hardware
Included
Display Span - Maximum
9,999
NEMA Enclosure Rating
12, 4
Product Type
Meter
Frequency Display - Minimum
2 Hz
Voltage Display - Maximum
600 V AC/DC
Frequency Display - Maximum
400 Hz
AC Voltage Input - Maximum
240 V AC
DC Voltage Input - Maximum
24 V DC
Terminal Connection Type
Internal Removable Terminal Blocks
Current Display - Minimum
0 A
AC Voltage Input - Minimum
100 V AC
Digital Display Screen Type
LCD
Voltage Display - Minimum
0 V AC/DC
Number of Display Digits
4
Digital Display Screen Color
Green, Red, White
Display Span - Minimum
9
Display Features
High Contrast

Description

Analog Panel Meter,600V
